ITW Simco-Ion IQ Power Installation And Operating Instructions Manual page 12

Web Speed Encoder and Wheel
IQ Power Static Bar
to PS COMM 2
Comm / Data Cable Construction
1 Crossover Wired
2 Straight Through Wired
DO NOT USE standard Ethernet cables Figures 5a & 5b.
Figure 8. IQ Power™ Connections (Power Supply to Power Supply)
IQ Power BPS
with AC Adapter
(static bar not shown)
Ground
Lead
Comm / Data Cable Construction
1 Crossover Wired
DO NOT USE standard Ethernet cables Figures 5a & 5b.
Figure 9. IQ Power™ Connections (Power Supply and Control Station)
I Q Power™ B PS
IQ Power Static Bar
IQ Power BPS
Connection
1
24 VDC
to PS COMM 1
Connection
Comm / Data (black)
to CS 1 thru 4
1
COMM ONLY
IQ Power BPS
24 VDC
to PS COMM 1
Connection
Comm / Data (black)
2
Reference color black
IQ Power
Control Station
to PS COMM 1
Connection
Comm / Data (black)
to CS 5 thru 10
POWER & COMM
10
24 VDC
to PS COMM 1
Connection
IQ Power
Communication Module
Power In Connector
Line Cord
AC Adapter
Reference color white
IQ Power BPS
without AC Adapter
(static bar not shown)
1
Reference color black
5 20 11 97 Re v. D
Ground
Lead
