ITW Simco-Ion IQ Power Installation And Operating Instructions Manual page 7

AC Adapter
Type
Input Power
Part Number
Output
Dimensions
Weight
Enclosure
Communication Module
Input Power
Communication Module
Dimensions
Weight
Operating Temp
Enclosure
Control Station
Input Power
Output Voltage
Interface
Dimensions
Weight
Operating Temp
Enclosure
I Q Power™ B PS
"Universal" desktop
100-240V 50/60Hz input (IEC 320 inlet)
4108774
24V , 3.75A maximum
132L x 60W x 34H mm
[5.19"L x 2.36"W x 1.34"H]
0.45 kg [1.0 lb]
Thermoplastic, black
24V , 1.0A from AC adapter
Anybus® CompactCom, see Replacement Parts / Additional Items
section for protocols available (units with Anybus®)
202L x 123W x 55H mm [7.95"L x 4.85"W x 2.15"H]
0.77 kg [1.70 lb]
43°C [110°F] max
Aluminum, blue polyester powder coated
100-240V, ~50/60Hz, 4A max (IEC 320 inlet)
24 VDC (IQ Power connectors 5 thru 10) (AUX connectors 1 & 2)
7" Color TFT LCD (backlit) with resistive touch screen
197H x 295W x 114D mm [7.75"L x 11.63"W x 4.50"H]
4.6 kg [10.1 lb]
39°C [102°F] max
Steel, blue polyester powder coated
4108104
24V
87L x 51W x 33H mm
[3.43"L x 2.00"W x 1.30"H]
0.2 kg [0.5 lb]
Thermoplastic, black
5
, 1.6A maximum
5 20 11 97 Re v. D
