PathFinder 350S Service Manual
1.

Introduction

The PathFinder 350S Specimen Sorter, hereafter referred to as the PathFinder 350S,
is an automated robotic workcell that registers and sorts specimen tubes into
sample racks.
This Service Manual details the parts and procedures required to carry out
configuration, repairs and preventative maintenance on the PathFinder 350S.
This manual is designed for use by Service Technicians. Only trained and certified
Service Technicians should attempt repairs on the PathFinder 350S Sorter.
The reader may also find relevant information in the following documentation



1.1

Safety Precautions

The PathFinder 350S complies with the safety requirements set out in IEC 61010-
1, Safety Requirements for Electrical Equipment for Measurement, Control, and
Laboratory Use, Part 1: General Requirements.
This manual contains warnings and cautions which, when properly followed, can
prevent personal injury and damage to the PathFinder 350S.
Technicians must observe all warnings and cautions outlined in this manual.
Warnings are presented in the following formats.
Page 8
PathFinder 350S User Manual (PS-U-UM002)
PathFinder 350S LIS Interface Manual (PS-U-UM008)
PathFinder 350S Spare Parts Catalogue (PS-U-SM010)
Highlights important information for the technician.
Alerts the reader to potential mechanical hazards that pose an injury risk
to the Technician and/or damage to the PathFinder 350S.
© Copyright 2010 Aim Lab Pty Ltd
NOTE
MECHANICAL HAZARD
Rev E February 2010
