Fence Hook – Sits over
the red strip.
Retention Strip
7.5.2

Adding Fences

1. Using the error rack fence as a reference, place the desired rack type against
2. When placing the fence, take note of the slot number the dowel pin sits in,
3. As a guide the fences should be separated by 11 slots for a 50-way rack, and 6
4. Repeat steps 1 thru 3 until all fences have been installed. Any unused space on
5. Turn over the Specimen Tray so the fence cables can be attached to the Tray
Page 104
Figure 77
Do not remove the error rack fence unless it is being replaced. It will be
used as a reference when rebuilding the tray.
The Error Rack fence should already be installed in slot 56.
the fence as a guide for where to place the next fence. For example if the gate
is to hold a PathFinder 50-way rack, place the rack against the error rack fence
as a guide.
refer to Figure 77. Every tenth slot is numbered on the tray.
slots for a 20-way rack. So for the gate next to the error rack, the fence should
be in slot 50 for a 20-way rack, or in slot 45 for a 50 way rack.
the tray should always be at the left hand side.
PCB. Each fence has two cables: a Rack Sensor Cable (labelled PS-E-A025) and a
Rack Indicator Cable (labeled PS-E-A026).
