OPERATING WITH THE NORMAL PROCESSING BOWL

WARNING: Always turn the appliance ›OFF‹, wait until the motor stops and
unplug the appliance before assembling/disassembling. Always completely assem-
ble your appliance before you plug the plug into the power outlet and ensure no
foreign substance is in the feed chute. Only touch the discs on the edge and blades
by its central plastic section and handle with care when cleaning.
1. Place the motor block on a suitable, stable, dry, and clean
working surface. (see: 'Safeguards for Daily Operation').
The control panel has to face the front.
2. Place the bowl on the motorblock turning it anticlockwise
until it is securely locked in position. Do not use any force.
The handle should be facing the front which is above the
control panel (picture A).
3. Fit the spindle onto the drive shaft, in the middle of the
processing bowl (picture B). The long shaft of the spindle
has to slide over the drive shaft and the end with the aglet
should face upright. If necessary turn the spindle a little to
fit in position. The spindle sticks out of the bowl for 1 or 2
cm.
Note: All attachments must be firmly attached to
the spindle. Always adjust the attachments until
you are sure that they are correctly fitted.
4. Put the disc or blade you want to use on top of the spindle
turning the disc until the hexagonal nut of the disc fits on the
hexagon bolt of the spindle (picture C/D). The side which
you want to use has to face upwards.
