CC-Link User Interface

The AS-i/CC-Link Gateway occupies 3 stations.
The CC-Link Master and the AS-i/CC-Link Gateway exchange data by Remote
Word Registers and RX/RY.
Device No.
RXn0
RXn1
RXn2
RXn3
RXn4
RXn5
RX(n+5) 0 ... RX(n+5) 9 Reserved
RX(n+5) A
RX(n+5) B
RX(n+5) C ... RX(n+5) F Reserved
Device No.
RYn0
RYn1
RYn2
RYn3
RYn4
RYn5
RYn5 ... RY(n+4) F
Subject to reasonable modifications due to technical advances.
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 · Internet http://www.pepperl-fuchs.com
Remote → Master
Description
Reserved
Reserved
Reserved
Reserved
0: RW use as Input and Output data image
1: RW use as mailbox
0: RW enabled, use RW as selected in RXn4
1: RW disabled
Error Status Flag
Remote READY
Master → Remote
Name
Offline
Auto_Address_Enable
Configuration mode
Protected Mode
Select
Select
Unused
AS-i/CC-Link Gateway
CC-Link User Interface
Description
1: the device is set into
the offline-phase
1: disabling of the auto-
matic slave addressing
changing this bit from 0 to
1 sets the device to con-
figuration mode
changing this bit from 0 to
1 sets the device to pro-
tected mode
0: Request for use RW
as Input and Output
data image
1:Request for use RW
as mailbox
0: Request for enable
RW, use RW as selec-
ted in RYn4
1:Request for disable
RW
