Appendix C: FMC Pin Assignments
Appendix C.1: GPIO Pins
Signal
LA00_CC_N
LA00_CC_P
LA01_CC_N
LA01_CC_P
LA02_N
LA02_P
LA03_N
LA03_P
LA04_N
LA04_P
LA05_N
LA05_P
LA06_N
LA06_P
LA07_N
LA07_P
LA08_N
LA08_P
LA09_N
LA09_P
LA10_N
LA10_P
LA11_N
LA11_P
LA12_N
LA12_P
LA13_N
LA13_P
LA14_N
LA14_P
LA15_N
Page 24
FMC (J1) FPGA
G7 AA6
G6 AA7
D9 Y7
D8 Y8
H8 AC6
H7 AC7
G10 AC4
G9 AB4
H11 AC8
H10 AB8
D12 W4
D11 W5
C11 W6
C10 W7
H14 U4
H13 U5
G13 AB5
G12 AB6
D15 V3
D14 V4
C15 V1
C14 V2
H17 Y1
H16 Y2
G16 W1
G15 W2
D18 AA1
D17 AA2
C19 AC3
C18 AB3
H20 AC1
Table 32 : GPIO Pins (continued on next page)
| FPGA
| N11
| P11
| R8
| T8
| M14
| M15
| N12
| P12
| K15
| L15
| K16
| L16
| N8
| N9
| K12
| L12
| L11
| M11
| K13
| L13
| R13
| T13
| R12
| T12
| M13
| N13
| L10
| M10
| V11
| V12
| U6
ADM-VPX3-9Z2 User Manual
V1.1 - 16th January 2020
FMC (J1) Signal
F5 HA00_CC_N
F4 HA00_CC_P
E3 HA01_CC_N
E2 HA01_CC_P
K8 HA02_N
K7 HA02_P
J7 HA03_N
J6 HA03_P
F8 HA04_N
F7 HA04_P
E7 HA05_N
E6 HA05_P
K11 HA06_N
K10 HA06_P
J10 HA07_N
J9 HA07_P
F11 HA08_N
F10 HA08_P
E10 HA09_N
E9 HA09_P
K14 HA10_N
K13 HA10_P
J13 HA11_N
J12 HA11_P
F14 HA12_N
F13 HA12_P
E13 HA13_N
E12 HA13_P
J16 HA14_N
J15 HA14_P
F17 HA15_N
