A data interface was implemented for this purpose (REST interface).
This interface responds to requests on port 3000 when valid parameters are
transmitted with data in the requested format.
ü A network connection has been established between the leak detector on one side
and the PC or Tablet on the other side.
See also "Operate leak detector via web browser (LAN) [} 123]" or "Operate leak
detector via web browser (wireless LAN) [} 125]".
ü The measurement data were recorded. See also "Switch on data recording and
configure export [} 75]".
► You have two options for exporting the desired measurement data:
ð You use the convenient options to first display measurement cycles and click
on . See also "Display measurement cycles [} 76]".
After activating the
measurement data is offered for download.
ð Alternatively, enter your request with the desired parameters as URL in your
browser. With this procedure, you not only set the desired time period (a
block of maximum 24 hours), but you can also select the file format and data
scope (with or without metadata).
Example 1:
http://192.168.11.124:3000/md?f=csv_en&c=4&d=mr
Returns measured values and metadata of the measurement cycle with ID 4 in the
format "csv_en".
Example 2:
http://192.168.11.124:3000/md?dts=2018-11-05T23:00:00.000Z&dte=
2018-11-06T23:00:00.000Z&f=json&d=r
Returns measured values between 2018-11-05T23:00:00.000Z und
2018-11-06T23:00:00.000Z in the "json" format.
Description
Querying one or more
measurement cycles via
ID
The start time of the time
period from which data is
to be exported.
The end time of the time
period from which data is
to be exported.
from the PC or Tablet, a file with the relevant
Options
ID's of the
measurement cycles.
Separated by comma
for several
A date in ISO format
in UTC time
A date in ISO format
in UTC time
Operation | 6
For example
c=3
c=3, 5, 8
dts=2018-08-02T17:15:12.000Z
dte=2018-08-02T17:45:35.000Z
