S tatus Indic ato rs
A.1 Fro nt Indic ato rs
A.1.1

S witch Indica tors

Front pa ne l LEDs a re loca te d on the right s ide of the cha s s is a nd dis pla y s ys te m, fa n, a nd powe r s upply
s ta tus . Appe ndix C
Figure A-1
Fig ure A-1: S ys te m S tatus Indic ato rs
Table A-1 S ys te m S tatus LED S tate s
LED S tate
Blinking Gre e n
Gre e n
Blue
Re d
Quick S ta rt Guide : 7000 S e rie s 1 RU-Ge n 2 Da ta Ce nte r S witche s
dis pla ys the front pa ne ls of a ll s witche s cove re d by this guide .
s hows 7124S X front pa ne l LEDs .
S tatus
S ys te m powe ring up.
All powe r s upplie s a nd fa ns a re ope ra ting norma lly.
The loca te r function is a ctive .
Two or more fa ns (a ny combina tion of fa n module s or P S U
fa ns ) a re dis conne cte d or ma lfunctioning. The s witch will
a utoma tica lly e xe cute a "gra ce ful s hutdown" s hortly.
Appe ndix A
21
