Cabling the S witc h

4.1 Co nne c ting Po we r Cable s
Impo rtant! Ins ta lla tion of this e quipme nt mus t comply with loca l a nd na tiona l e le ctrica l code s . If ne ce s s a ry, cons ult
with the a ppropria te re gula tory a ge ncie s a nd ins pe ction a uthoritie s to e ns ure complia nce .
The s witch ope ra te s with two ins ta lle d powe r s upplie s . At le a s t one powe r s upply mus t conne ct to a
powe r s ource . Two circuits provide re dunda ncy prote ction.
powe r s upplie s on the re a r pa ne l of the s witch.
Impo rtant! Re a d a ll ins ta lla tion ins tructions be fore conne cting the s ys te m to the powe r s ource .
• No n-Re dundant Co nfig uratio n: Conne ct powe r to e ithe r of the two powe r s upplie s .
• Re dundant Po we r S upply Co nfig uratio n: Conne ct powe r to both powe r s upplie s .
• Po we r do wn the S witc h: Re move a ll powe r cords a nd wire s from the powe r s upplie s .
Impo rtant! This e quipme nt mus t be grounde d. Ne ve r de fe a t the ground conductor.
Impo rtant! This unit re quire s ove rcurre nt prote ction.
4.1.1

AC P owe r S upply

The AC powe r s upply conne cts to a circuit tha t provide s 100-240 VAC, 50 or 60 Hz, a nd 5.29-2.2 A.
Figure 4-1
The powe r s upplie s re quire powe r ca ble s tha t comply with IEC-320 a nd ha ve a C13 plug. The
a cce s s ory kit provide s two IEC-320 C13 to C14 powe r ca ble s , e a ch two me te rs long.
Fig ure 4-1: AC Po we r S upply
Quick S ta rt Guide : 7000 S e rie s 1 RU-Ge n 2 Da ta Ce nte r S witche s
dis pla ys a n AC powe r s upply, including the powe r s ocke t on the right s ide of the module .
Chapte r 4
Appe ndix D dis pla ys the loca tion of the
15
