Matrox Meteor-II /Digital Installation And Hardware Reference page 55

54 Appendix B: Technical information
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
PIN SIGNAL
29
DATA, INPUT, 14+
30 DATA, INPUT, 14-
31 DATA, INPUT, 15+
32
DATA, INPUT, 15-
33 HSYNC, INPUT, +
34 HSYNC, INPUT, -
35
VSYNC, INPUT, +
36 VSYNC, INPUT, -
37 GROUND
38
GROUND
39 CLOCK, INPUT, +
40 CLOCK, INPUT, -
41
USER, INPUT, 0+
42 USER, INPUT, 0-
43 USER, INPUT, 1+
44
USER, INPUT, 1-
45 VALID, INPUT, +
46 VALID, INPUT, -
47 TRIGGER, INPUT, +
48 TRIGGER, INPUT, -
49 CAMERA CTRL BIT0,
OUTPUT, TTL
50 GROUND
Customize the open-ended Matrox DBHD100-TO-OPEN input
cable to interface with the connector on your video source. For
customers planning to build their own cable, parts for the
mating connector can be purchased from:
Manufacturer:
■
Connector and shell:
■
If you are building your own cable, ensure that it is a
twisted-pair type cable which is twisted along signal pairs.
PIN SIGNAL
79
DATA, INPUT, 30+
80 DATA, INPUT, 30-
81 DATA, INPUT, 31+
82
DATA, INPUT, 31-
83 HSYNC, OUTPUT, +
84 HSYNC, OUTPUT, -
85
VSYNC, OUTPUT, +
86 VSYNC, OUTPUT, -
87 EXPOSURE1, OUTPUT, TTL
88
EXPOSURE2, OUTPUT, TTL
89 CLOCK, OUTPUT, +
90 CLOCK, OUTPUT, -
91
USER, OUTPUT, 0+
92 USER, OUTPUT, 0-
93 USER, OUTPUT, 1+
94
USER, OUTPUT, 1-
95 EXPOSURE1, OUTPUT, +
96 EXPOSURE1, OUTPUT, -
97 EXPOSURE2, OUTPUT, +
98 EXPOSURE2, OUTPUT, -
99 CAMERA CTRL BIT1,
OUTPUT, TTL
100 CAMERA CTRL BIT2,
OUTPUT, TTL
ACON Advanced-Connectek Inc.
HBP50-1AK3202
