32 Chapter 4: Using multiple Matrox Meteor-II boards
.
Camera 1
Camera 2
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
If you are installing an additional Matrox Meteor-II board on
Matrox 4Sight or Matrox 4Sight-II, the board already installed
has the setting fixed at 0; therefore, the setting of the additional
board must be at a setting other than 0 or 4.
Grabbing simultaneously from different
boards
You can simultaneously grab images from cameras attached to
different Matrox Meteor-II boards. To grab at exactly the same
time, the cameras must be genlocked (synchronized).
The number of cameras from which you can simultaneously
grab is determined by the PCI bandwidth available in your
computer.
Matrox Meteor-II
Matrox Meteor-II
Grabbing from two Matrox Meteor-II boards
