About the development board
HDMI interface
The development board provides an HDMI interface connected to the display interface 1 of the
ConnectCore for i.MX51 CPU. An Analog Devices AD9389 HDMI transmitter is used in the development
board. This HDMI transmitter is controlled through the I
2
The I
C device address of the HDMI transmitter is the following:
Interface
HDMI transmitter (AD9389)2
HDMI connector, J19
The development board provides an HDMI connector, J19. The HDMI interface is connected to the
Display 1 interface of the ConnectCore for i.MX51 CPU.
The table below shows the pinout of the HDMI connector:
ConnectCore for i.MX51 Hardware Reference Manual
2
C port 2 of the ConnectCore for i.MX51.
2
I
C Address (7 bits)
0 x 39
HDMI interface
85
