About the development board
Pin Function
13 JTAG_TDO
15 JTAG_RESET#
17 JTAG_DE#
19 GND
Note In order to enable ETM functionality, Digi offers an optional ETM adapter board (sold separately,
Digi P/N CC-ACC-MX51-ETM). Please contact us.

LCD interfaces

The development board provides two 2x40 pin, 1.27mm connectors for accessing a Digi-provided LCD
application boards (CC-ACC0LCDW-70) or a user defined LCD application board.
ConnectCore for i.MX51 Hardware Reference Manual
Pin Function
14 GND
16 GND
18 GND
20 GND
LCD interfaces
90
