#EMG2000 MAGNUM™ DC LED Lightbar
DIRECT CONNECT FLASH PATTERNS AND CONNECTOR INSTRUCTIONS
40Amp FUSE
(Customer Supplied)
GROUND
GROUND
Low Power (Standby) Mode
If there is no +Vdc input to the 12 conductor discrete wire harness for 180 seconds the lightbar will go into a "Standy" mode. The standby mode is a low power
mode that is used to extend the life of your battery. The lightbar will awaken from the Standby mode if any input (except pattern select) is connected to +Vdc.
# Pattern Name Sequence
1 Quint Alternating
2 Warp Alternating
3 Inter-Cycle Flash Alternating
4 Quad Flash Alternating
5 RoadRunner Alternating
6 RoadRunner Simultaneous
7 Slow Runner Alternating
8 Slow Runner Simultaneous
9 Q-Switch Variable
10 Single, Steady Burn Steady Burn
11 Quad, Steady Burn Steady Burn
12 Warp, Steady Burn Steady Burn
13 Nothing, Steady Burn Steady Burn
14 E-Single Flash Alternating
15 E-Double Flash Alternating
16 E-Single Flash Simultaneous
17 E-Double Flash Simultaneous
18 Warp 1,2,3,4 Variable
19 Warp 2,3,1 Variable
20 Warp 3,2,1 Variable
21 Steady Burn Steady Burn
*fpm=Flashes per Minute
**fps=Flashes per Second
9
DRAIN WIRE
BLACK 12 GA.
fpm* fps**
Wire Color
70 1.18 Pink
350 5.88
Orange
- - Violet
80 1.35 Red
115 1.92
Tan
115 1.92 Black
70 1.16 White
70 1.16
Brown
- - Gray
115 1.92 Blue
80 1.35 Green
350 5.88 Yellow
- -
125 2.08
1 Road Runner Alternating
125 2.08
2 PowerPulse
125 2.08
3 Q-Switch
125 2.08
4 ETM
- -
5 Steady Burn
- -
- -
- -
Standard Functions
Take Downs
Alley Driver Steady Burn
Left Turn
Stop
Corners
Low Power
Pattern Select
Alley Passenger Steady Burn
Inboards 2, 3
Inboards 1
Right Turn
Tail
LED Take down Flash Pattern
115
Alternating 180
Variable -
Simultaneous 214
Steady Burn -
Note: Alley Driver & Passenger
are Steady Burn only
*Refer to page 11 for input group
control and switch setting
Auxiliary Output
The lightbar is equipped with one 3.5A auxiliary output.
1.92
Connect +10-30Vdc or an external flasher output to
3.00
Aux_In using a .250" female spade terminal or apply
-
power to the Pink wire for activation. Connect ground
3.57
and power of Auxiliary Light to GND and AUX_OUT
-
using .250" female spades.
EMG2000-DC 10.15
