#EMG2000 MAGNUM™ DC LED Lightbar
TOP VIEW WITH COVERS ON
TOP COVER SCREWS
TOP VIEW WITH COVERS OFF
INBOARD LED
MODULES
CORNER MODULE
BOTTOM VIEW
3
MODEL NUMBER
& SERIAL NUMBER
LOCATIONS
MAIN ELECTRICAL
BOARD
5/16 Carriage Bolts for
Mounting Feet of Lightbar
Wire Exit Holes
TECHNICAL SPECIFICATIONS
Aluminum Base, Nylon base end
caps, polycarbonate outer lenses,
Material:
acrylic inner lenses .
Roof Attachments:
Operating Temperature:
LENGTH # OF INBOARDS
23"
35.5"
41.8"
48"
54.3"
60.5"
73"
POWER SPECIFICATIONS
Input Voltage Range:
Light Bar Current Draw
Component (Average = Flashing)
Standby Current .022 Amps
Reverse Polarity
Load Dump
Power Cable 15ft 10 AWG Wires, (+) Red, (-) Black
Wiring
Optional 16ft. 22AWG 12 conductor Direct Connect Harness
1/4" bolt Stainless A2
-40º to +65º C
DIMENSIONS
2
4
5
12.4"D x 2.3H
6
inboard
7
8
10
10 -16 Vdc
Power Consumption
(Watts)
.28 Watts
Fuse Protected
Protected
Data Cable 15ft RJ-45 Type
EMG2000-DC 10.15
