Soundoff Signal nROADS Instruction Manual

LED Lightbar - Single Color
9 8 7
G
F
E
D
C
IMPORTANT NOTICE TO INSTALLER: Make sure to read and understand
all instructions and warnings before proceeding with the installation of this
product. Ensure that the manual and any warning cards are delivered to the
B
end user of this equipment. Proper installation of the lightbar requires the
installer to have a thorough knowledge of automotive electronics, systems,
and procedures. Lightbars provide an essential function of an effective visual
A
9 8 7
warning system. The use of the lightbar does not ensure that all drivers can
or will abide by or react to an emergency warning signal, especially at high
rates of speeds or long distances. The operator of the vehicle must never take
the right of way for granted and it is the operator's responsibility to proceed
safely. The effectiveness of the lightbar is highly dependant on the correct
mounting and wiring. The installer must read and follow the manufacturer's
installation instructions and warnings in the manual. The vehicle operator
should verify daily that the lightbar is securely fastened to the vehicle and
properly functioning before operating vehicle. The lightbar is intended for use
by authorized personnel only. It is the user's responsibility to ensure they
understand and operate the emergency warning devices in compliance with
the applicable local, state and federal laws and regulations. SoundOff Signal
assumes no liability for any loss resulting from the use of this warning device.
Components/Contents
Standard Equipment:
1 - nROADS Fleet LED Lightbar built to your specifications
®
Other Parts that may be included depending on your configuration:
1 - Vehicle Specific Hook Kit w/ Hardware*
2 - Fixed Height Mounting Brackets w/ Hardware or
1 - Flat Mount Hardware Kit or
2 - Headache Brackets w/ Hardware
*Kits will vary with each lightbar depending on vehicle specified on order form.
Unpack Lightbar
1. Remove the lightbar from box and packaging.
2. Save packaging for later shipping.
3. Check components/contents.
4. Please reference these instructions for proper wiring and installation.
Tools Required for Installation
• 7/16" Socket with ratchet
• Phillips Head Screwdriver
• Drill bit #30
1.800.338.7337 / www.soundoffsignal.com
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning devices. Improper use or installation may void
warranty coverage. To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product, visit our website at www.soundoffsignal.com/sales-
support. If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. or after hours 5 p.m. to 8 p.m. EST at 1.800.338.7337 (press
#4 to skip the automated message). Questions or comments that do not require immediate attention may be emailed to techservices@soundoffsignal.com.
S U P E R I O R C U S TO M E R R E L AT I O N S H I P S . S M A RT LY D E S I G N E D L I G H T I N G & E L E C T R O N I C S O L U T I O N S .
1.
6 5 4 3
MESA_LIGHT_BAR_ASSEMBLY-INSTALL.SHEET.UPDATES
6 5 4 3
TABLE OF CONTENTS
PAGE
2 1
1
G
2
F
3 TECHNICAL/ POWER SPECIFICATIONS
4 FIXED HEIGHT BRACKETS AND HOOK MOUNTING
E
5
D
6
C
7-10
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN
THIS DRAWING IS THE SOLE
PROPERTY OF SOUNDOFF SIGNAL. 11
® ANY REPRODUCTION IN PART OR B
AS A WHOLE WITHOUT THE
TOLERANCES WRITTEN PERMISSION OF
SOUNDOFF SIGNAL IS PROHIBITED.
EXCEPT AS NOTED
.X ± .020
THIRD ANGLE
.XX ± .012 CAD DIMENSIONS ARE BASIC
.XXX ± .006 PROJECTION UNLESS OTHERWISE SPECIFIED
ANGLES ± .5°
DRAWING B
PRIMARY DIMS: INCH
GD&T TO FOLLOW SIZE:
DUAL DIMS: [mm]
ASME Y14.5M-1994 DO NOT SCALE
MATERIAL:
12
DESCRIPTION:
MESA LIGHT BAR ASSEMBLY
A
DRAWING NO: REVISION:
1 OF 3
SHEET
2 1 13
14 WARRANTY AND RETURN GOODS PROCEDURE
Important Information:
• Warning devices are strictly regulated and governed by Federal, State
and Municipal ordinances. These devices shall be used ONLY on approved
vehicles. It is the sole responsibility of the user of these devices to ensure
compliance.
• DO NOT install this product or route any wires in the Air Bag Deployment
Zone. Refer to your vehicle Owner's Manual for the location of any air
bag deployment zones.
• DO NOT connect this device to a strobe power supply. This product is
self-contained and does not require an external power supply.
NOTICE:
CONTENT
COMPONENTS/ CONTENTS
MODULE SPECIFICATIONS
GASKET MOUNTING & WIRE SLEEVE
INSTRUCTIONS
INPUT WIRE DEFINITIONS
ELECTRICAL INSTALLATION
LIGHT MODULE REPLACEMENT
nROADS TROUBLESHOOTING
REPLACEMENT PARTS
WARNING
!
This product contains high intensity LED devices. To
prevent eye damage, DO NOT stare into the light
beam at close range.
nROADS Lightbar_Single Color - English 0820
