This section contains general information and a detailed specification of the UST100-504-FL.
Section 1 consists of the following sub-sections:


General Descriptions

 System Specifications
 Dimensions
 I/O Outlets
 Packing List
1.1 General Descriptions
The UST100-504-FL is a fanless embedded system powered by 7
Core™ i7/i5/i3 processor and Celeron
and comes with flexible I/O design. To fulfill different application needs, this flexible embedded
system supports Windows
be wall-mounted as an optional request.
The UST100-504-FL is built with an IP30-rated heavy-duty aluminum extrusion, enabling
reliable operation in harsh environments. Moreover, it features a wide range of 9 to 36V DC
power input with power protection, and supports extended operating temperatures from -40 °C
to +60 °C. To help minimize deployment time, this fanless embedded PC provides one
optional I/O door for customers to easily install additional I/O output, making it perfectly
suitable for any industrial grade applications.
Introduction
®
processor (formally codenamed: Kaby Lake / sky lake)
® th ®
7 (for 6 Gen Intel
UST100-504-FL Series user's Manual
INTRODUCTION
th
®
CPU, Windows 10, Ubuntu 18.04, and can
SECTION 1
th ®
/ 6 generation Intel
1
