PR Lighting PR-8102 Product Manual

Diamond 3w x 108 rgbwa zoom
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DIAMOND（3W X 108）RGBWA ZOOM
PR-8102
This product manual contains important information about the safe installation and use of this
projector. Please read and follow these instructions carefully and keep this manual in a safe place
for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PR-8102 and is the answer not in the manual?

Questions and answers

Related Manuals for PR Lighting PR-8102

Summary of Contents for PR Lighting PR-8102

  • Page 1 DIAMOND（3W X 108）RGBWA ZOOM PR-8102 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...
  • Page 2 INDEX SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR POWER SUPPLY – MAINS CONTROL CONNECTIONS DMX TERMINATOR SETUP OPTIONS-PROJECTOR CONFIGURATION TO SET THE DMX START ADDRESS MASTER/SLAVE MODE STAND-ALONE MODE OPERATION MENU REPLACING GOBOS DMX PROTOCOL INDICATION OF LED DIGITAL TUBE MAINTENANCE LUBRICATION KEEPING THE PROJECTOR CLEAN...

  • Page 3: Safe Usage Of The Projector

    SAFE USAGE OF THE PROJECTOR When unpacking and before disposing of the carton check there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The projector is for indoor use only, IP20.

  • Page 4: Install The Projector

    INSTALL THE PROJECTOR 吊钩 警告 请把安全绳穿过此保险 绳连接孔以确保安全 保险绳 保险绳连接孔 可伸缩式提手 Take 2 clamps and 1 safety cord out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to each clamp. Hang the fixture on the structure and fasten the screws attached to each clamp. (See the WARNING on the underside of the base as shown above) Always ensure that the projector is firmly anchored to avoid vibration and slipping whilst functioning.

  • Page 5: Power Supply-Mains

    POWER SUPPLY-MAINS Connect the power cord as follows: L (live) =brown E (earth) =yellow/green N (neutral) =blue Use the plug provided to connect the mains power to the projector paying attention to the voltage and frequency marked on the panel of the projector. It is recommended that each projector be supplied separately so that they may be individually switched on and off.

  • Page 6: Dmx Terminator

    DMX TERMINATOR In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control signals. The DMX terminator is simply an XLR connector with a 120 (ohm) resistor connected across pins 2 and 3, which is then plugged into the output socket on the last projector in the chain.
  • Page 7 Press button FUNC to display DMX address; Press button UP and DOWN, you can set the address; Press button ENTER to confirm; Press button FUNC, it will return to the upper menu one by one. 7/22...

  • Page 8: Operation Menu

    OPERATION MENU Level Level 1st LEVEL 2nd LEVEL 3rd LEVEL 4th LEVEL AddR DMX Address DMX Address Reset Reset Are You Sure DMX Mode Standard 16 DMX mode DMX Mode Extended 16 DMX Mode Short 8 XLED 3108 ZOOM FIXTURE TYPE= XLED 590 ZOOM W XLED 3108 ZOOM...
  • Page 9 Defaults Restore Defaults Display On Always Display Mode Display Off After Delay Display Options Display Invert Display Invert Display Invert Disp Dim Level Disp Dim Level Disp Dim Level Disp Dim Level Disp Dim Level Disp Dim Level Display Dimming Disp Dim Level Disp Dim Level Disp Dim Level...
  • Page 10 Head Sensor = Head Sensor XX℃ Display Board = Software Version Display Board *.*.* DMX Channel View DMX Values XXX=XXX Electronic SN = Electronic SN ************ Factory Setup Calibration Menu Factory Setup Factory Setup ON( UP,DOWN,ENTER Calibration Menu Green pressed together to Green Test Modes enter Color Calibration...
  • Page 11 Select Memory Preset Memory 3 Operation Mode = Static Scene Dimmer Dimmer User Memories Color Temp. Color Temp. RGB Macros RGB Macros Edit User Memory Green Green Blue Blue User Memory Scene white white Amber Amber Zoom Zoom Strobe Strobe Pan Coarse Pan Coarse Pan Fine...
  • Page 12 Dimmer Dimmer Color Temp. Color Temp. RGB Macros RGB Macros Green Green Blue Blue white white User Memory Amber Amber Scene Zoom Zoom Strobe Strobe Pan Coarse Pan Coarse Pan Fine Pan Fine Tilt Coarse Tilt Coarse Tilt Fine Tilt Fine M-Speed M-Speed Delay...
  • Page 13 Green Green Blue Blue white white Amber Amber Zoom Zoom Strobe Strobe Pan Coarse Pan Coarse Pan Fine Pan Fine Tilt Coarse Tilt Coarse Tilt Fine Tilt Fine M-Speed M-Speed Delay Delay X.XX Seconds Link To Step Link To Step Init User Memory Reset User Reset User 1...

  • Page 14: Dmx Protocol

    DMX PROTOCOL Short Standard Extended FUNCTION DESCRIPTION mode mode mode Dimmer Dimming from dark to light (0-100%) 000-255 Dimmer Fine Dimmer in 16 Bit precision 000-255 Colour CT Adjustment 000-255 Temperature Light Control by RGB channel 000-016 017-024 White(10000K) White(7200K) 025-032 033-040 White(5600K)

  • Page 15: Indication Of Led Digital Tube

    Speed 4 048-063 Speed 5 064-079 Speed 6 080-095 Speed 7 096-111 Speed 8 112-127 Speed 9 128-143 Speed 10 144-159 Speed 11 160-175 Speed12 176-191 Speed 13 192-207 Speed 14 208-223 Speed 15 224-239 Speed 16,Slowest 240-255 Reserved 000-047 Control Reset 048-080...

  • Page 16: Troubleshooting

    TROUBLESHOOTING PROBLEM ACTION  The projector doesn’t switch on Check the fuse on the power socket.  The lamp comes on but the projector Make sure that the projector is correctly configurated.  doesn’t respond to the controller Replace or repair the DMX cable. ...

  • Page 17: Technical Data

    TECHNICAL DATA VOLTAGES: 100V/120V/200V/220V/230V/240V AC，50/60Hz POWER CONSUMPTION: 360W@220V LED: OSRAM OSTAR CP7P Model Power consumption 108 （24R＋24G＋24B+24W+12A） Quantity Manufacturers Rated LED Life 50000 Hours COLOURS: RGBW linear color mixing with Macro COLOR TEMPERATURE CORRECTION Linear color temperature correction from 3200K to 10000K DIMMER: 0-100% linearly adjustable STROBE:...
  • Page 18 Self Test Mode OTHER FUNCTIONS: Pan & Tilt Speed adjustable Auto speed adjustment of Fans LED Lamp Overheating Protection Display’s Brightness and Contrast adjustable Lamp/Projector use Time display DMX512 Channel Value Display Menu Invert HOUSING: High temperature ABS +die-casting aluminum, IP20 WORK ENVIRONMENT TEMPERATURE: -20°C~40°C WEIGHT:...
  • Page 19 LIGHT OUTPUT: 35°LUX 1728 PR-8102 23°LUX 3631 11.03° 19.56° DISTANCE(m) 23°DIAMETER(m) 2.08 4.16 6.24 8.32 10.40 12.48 35°DIAMETER(m) 3.10 6.20 9.30 12.41 15.51 18.61 19/22...
  • Page 20 20/22...

  • Page 21: Component Order Codes

    COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK 190010110 POWER SWITCH 192010147 POWER SWITCH 290151223 BELT(Premium Fiber ) 290151256 BELT 270041037 FUSE(VDE CERTIFICATE) 150020217 LED(RED) 150020218 LED(BLUE) 150020219 LED(GREEN) 150020220 LED(WHITE) 150020221 LED(YELLOW) 290010166 3W LED SECONDARY LENS 290010167 3W LED FIRST LENS 030040052 STEPPER MOTOR(A CLASS) 030040162...
  • Page 22 PR LIGHTING LTD. 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 320050021 Version: 20120706 (Preliminary） 22/22...
