2. A warning dialog is displayed on the TOUCH SCREEN until acknowledged.
3. The ALARM LED flashes until acknowledged, and then turns solid red.
Tap the TOUCH SCREEN or touch any codec controls to acknowledge the alarm and stop the alarm
tones.
Touch Screen Battery Indications
The percentage of battery charge remaining is displayed next to the battery symbol in the Status
Bar on the TOUCH SCREEN. In addition:
· When power is attached to the codec the BATTERY symbol is green and the white Power
symbol is displayed.
· When operating on battery power the BATTERY symbol is white.
Symbol
HTML5 Toolbox Web-GUI Low Battery Indications
A low battery icon is displayed in the HTML5 Toolbox Web-GUI when the battery level is 20 percent
or lower. This flashes until it is acknowledged on the unit itself.
© Tieline Research Pty. Ltd. 2020
Battery State
Power is attached to the codec and the battery is charging.
The battery is fully charged and no power is attached to the codec.
The battery is fully charged and the external power supply is in use.
Unknown battery error while the external power supply is attached. The battery
should immediately be removed from the codec. Please contact Tieline if this
situation persists.
Unknown battery error. The battery should immediately be removed from the
codec. Please contact Tieline if this situation persists.
The battery is too hot or too cold. Move the codec to a cooler or warmer
location as required.
The battery has overheated or is faulty. For safety reasons the battery will be
prevented from discharging and powering the codec. Plug in external power to
prevent imminent shutdown. The battery MUST be removed from the codec and
allowed to cool.
An external power supply is attached and the battery is too hot or too cold and
not charging. For safety reasons, the battery is prevented from charging if the
internal temperature is above or below pre-set thresholds. Move the codec to a
cooler or warmer location as required, to allow the battery to continue charging.
An external power supply is attached and the battery has overheated or is
faulty. For safety reasons the battery is prevented from charging, or
discharging and powering the codec. The battery MUST be removed from the
codec and allowed to cool.
