10 ViA User Manual v3
3 Inserting and Removing Modules
A single module slot is available on the codec rear panel for inserting an optional cellular, ISDN or
POTS module into the codec.
Inserting or Removing a Module
Ensure the codec is [OFF] when inserting or removing modules. Where possible use anti-
static precautions to help minimize the chance of static charges damaging the highly
sensitive circuitry. Do not force a module into the codec. Modules should be installed
slowly and gently.
1. Press the POWER
2. Remove the 4 screws from the blanking panel or module installed in the codec.
3. Carefully slide the new module into the module slot and ensure the base of the module remains
flat during insertion, to ensure it lines up correctly with the module connector in the codec.
4. Reinsert the 4 screws to hold the module firmly in place.
5. Press the POWER
6. Press the HOME
7. Tap Transport Interfaces to expand the menu and tap ISDN Module, POTS Module or
Cellular > Cellular Module to configure module settings.
4 Wireless IP Connection Options
The codec has multiple IP interface connection options, including:
1. LAN1 Ethernet port (default Primary Via interface)
2. LAN2 Ethernet port (default Secondary Via interface)
3. Internal Wi-Fi (default Tertiary Via interface)
4. External USB PORT 1. Note: for use with a USB modem or tethered smartphone.
5. External USB PORT 2. Note: for use with a USB modem or tethered smartphone.
6. Optional Internal Single SIM LTE Module. Note: two antennas are shipped with this module to
support diversity.
7. Optional Internal Dual Active SIM LTE Module: Note: Requires firmware v2.20.xx or higher and
four antennas are shipped with this module to support diversity.
For more information about prioritizing the interface used when dialing a connection see Configuring
Via Interfaces.
Connecting a Wi-Fi Access Point
To connect the codec to a Wi-Fi network access point:
1. Press the HOME
ViA codec with an ISDN module installed
button and tap Shut Down to turn the codec [OFF].
button to power up the codec.
button to return to the Home screen and tap Settings
button to return to the Home screen, then tap Settings
.
.
