Codec Tieline ViA Quick Start User Manual page 41

3. Enter a custom headphone mix name and tap Done, or tap the file symbol to select an
existing Custom HP Mix to either edit or overwrite it.
4. The custom mix will be saved and loaded and is displayed in the Headphone screen.
Important Notes:
· The mix displayed for Headphone 1-3 in the panel is reflected in the loaded mix in the
Matrix Editor. If you create custom headphone mixes and load them, and then save all
routing in the Matrix Editor as a custom matrix, all the custom headphone mixes and
their Send/Return balance settings are also saved. In essence, custom headphone
mixes are "attached" to a Matrix Editor matrix when it is saved. This is displayed in the
codec as per the following image. In this example, "Basketball" is the name of the
custom Matrix Editor matrix and "Glenn mix" is the name of the custom headphone mix
attached to this matrix.
· If a custom headphone mix is saved with a custom matrix and the headphone mix is
subsequently deleted, the custom headphone mix settings are retained in the saved
custom matrix.
· Individual headphone source level adjustments for each headphone output are not saved
with a Matrix Editor custom matrix. These individual source levels are accessed by
swiping left in the Headphone Mix view on the TOUCH SCREEN.
Load a Custom Headphone Mix
To load a saved custom headphone mix:
1. Press the SOURCE button to display the headphone monitoring screen.
2. Tap Menu
© Tieline Research Pty. Ltd. 2020
and then tap Browse.
ViA User Manual v3 41
