18 ViA User Manual v3
Feature
1 Audio Stream name /
button
2 Connect button
3 Connection
TieLink selector
4 Dialing destination
5 Destination settings
6 Add SmartStream PLUS Tap the Plus symbol to add a SmartStream PLUS dialing
7 Connection settings
8 Information (statistics)
9 Expand / Collapse
10 PPMs
11 'Hamburger Menu'
12 Program name
The codec is configured to connect in mono over IP by default when shipped, or when factory default
settings are restored.
1. Ensure the codec is not powered up when inserting or removing modules.
2. Attach the 12VDC power supply to the codec or insert the charged BATTERY. Note: the
BATTERY is automatically charged inside the codec when the power supply is connected.
3. Attach headphones and microphones to the codec.
4. Press the POWER
Description
Displays the audio stream name; tap to edit audio stream
settings, including Stream Name, Caller ID, Routing Type, G3
Profile Type, G3 Channel.
Tap the Connect button to dial a connection.
type / Tap to toggle between selecting whether to dial a configured
IP/SIP, ISDN or POTS connection, or a TieLink Address Book
contact.
Tap to enter an IP/SIP address or ISDN/POTS number, or select a
TieLink Contact list contact if TieLink is configured.
Tap to configure destination settings, e.g. dialing interface and IP
ports.
connection. By default, the last configured IP address is inserted
in a new SmartStream PLUS connection.
Tap to adjust
Algorithm, Auto Reconnect, Jitter Buffer, FEC, Direction, Auxiliary
Data, Connection Name.
Tap to view audio stream connection statistics, e.g. Link quality,
packet statistics. Swipe in this screen to view other active audio
stream statistics.
Tap to expand or collapse the audio stream information displayed.
Audio stream PPMs for send and return audio in dBFS by default.
Tap to load a default or custom program, or create a new program
and save it as a custom program. Switch between Basic and
Admin modes of operation.
The name of the loaded program.
button to power up the codec.
connection-related settings
© Tieline Research Pty. Ltd. 2020
like Transport,
