Specifications

These product specifications may change without prior notice.
Video
Image Sensor
Max. Resolution
Scanning Mode
Lens type
Focal Length
Aperture
Iris Control
Angular Field of 5M (2592 x
View 1944)
4M (2592 x
1456)
Min. Illumination
Dynamic Range
Electronic Shutter Speed
Day & Night
IR Distance (LEDs)
Pan/Tilt Range
Network
Video Compression
Bit rate Control
Max. Frame Rate
Audio Compression
Supported Resolution
Multi-Video Streaming
Ethernet
1/2.8" CMOS
2592 x 1944 (4:3)
2592 x 1456 (16:9)
Progressive Scan
Motorized Vari-focal
f=2.7 - 13.5mm
F=1.4 ~ 3.2
DC Iris
H : 101.2° (WIDE ) ~ 30.4° (TELE)
V : 72.57° (WIDE ) ~ 22.8° (TELE)
D : 137.4° (WIDE) ~ 38° (TELE)
H : 101.7° (WIDE ) ~ 30.2° (TELE)
V : 53.3° (WIDE ) ~ 17° (TELE)
D : 121.6° (WIDE) ~ 34.7° (TELE)
COLOR : 0.15 lux @ F1.4
B/W : 0 lux (IR LED ON)
120dB, True WDR
Auto / Manual (1/30 ~ 1/10,000), Anti-Flicker, Slow Shutter (25 ips: 1/12.5, 1/6.25
30ips: 1/15, 1/7.5)
IR cut filter with auto switch
30m (6ea)
Pan: -175° ~ 175°, Tilt: 0° ~ 64°, Rotate: -177° ~ 177°
H.265, H.264(MP), M-JPEG
CBR / VBR
4:3 mode : 30fps : 2592 x 1944(WDR)
16:9 mode : 30fps : 2592 x 1456(WDR)
G.726, ADPCM-16K, G.711u-Law, G.711a-Law
4:3 : 2592x1944, 1920x1440, 1280x960, 640x480
16:9 : 2592x1456, 1920x1080, 1280x720, 640x360
Quadruple
RJ45(10/100BASE-T)
Part 3 - Appendix
21
