6.5 RS-232 Control

UNIT
Pin Pinout
1
2 Tx
3 Rx
4
5 GND
6
7
8
9

6.6 RS-232 Commands

Command
?
HELP
OUT N1
OUT ?
SOURCEDET
SINKINFO
HDCPIN N1 N2
TERMINAL
Pin Pinout
1
2 Rx
3 Tx
4
5 GND
6
7
8
9
Description and Parameters
Show the full command list.
Show the full command list.
Select the input to display.
Available values for N1:
1~4
0
Show which input is currently selected.
Show the current input detection status.
Show information about the connected display.
Set the HDCP mode for input N1.
N1 = 1~4 [Input number]
Available values for N2:
1
2
3
SERIAL PORT SETTINGS
Baud Rate
Data Bits
Parity Bits
Stop Bits
Flow Control
[Input number]
[Mute]
[Follow in]
[Follow out]
[HDCP Disabled]
115200
8
None
1
None
4
