6.2 Rear Panel

OUTPUT INPUT 4
1
1 OUTPUT: Connect to HDMI TVs, monitors or amplifiers for digital
video and audio output.
INPUT 1~4: Connect to HDMI source equipment such as media
2
players, game consoles or set-top boxes.
3 RS-232: Connect directly to your PC/laptop to send RS-232
commands to control the unit.
SERVICE: This slot is reserved for firmware update use only.
4
5 DC 5V: Plug the 5V DC power adapter into the unit and connect it
to an AC wall outlet for power.

6.3 Remote Control [Optional]

POWER: No function.
1
2 INPUT 1~4: Press any of these buttons to switch
to the corresponding input.

6.4 IR Cable Pinouts [Optional]

IR Extender
3
INPUT 3 INPUT 2 INPUT 1
2
Infrared
1
Power
2
3
Ground
RS-232
SERVICE
DC 5V
3 4 5
1
1
2
3
INPUT
POWER
2
4
CR-72
