Maintenance
Rear Suspension Spring Preload
Adjustment
The spring preload adjuster is located
next to the rear suspension unit.
1
1. Spring preload adjuster
To change the spring preload setting:
• Look upwards from the bottom of
the spring preload adjuster to the
top of the spring preload adjuster,
and rotate the adjuster clockwise
to increase and anticlockwise to
decrease.
• Always count
adjuster clicks/turns anticlockwise
from the fully clockwise position.
Note
The motorcycle is delivered from the
factory with the spring preload setting
in the fully anticlockwise (minimum)
position.
138
the number of
Rear Suspension Rebound Damping
Adjustment
The rebound damping
located behind the side panel on the
right hand side of the motorcycle.
1. Rebound damping adjuster
To change the rebound damping setting:
• Remove the right hand side panel,
see page 81.
• Insert a flat
into the slotted rebound damping
adjuster.
• Rotate the
adjuster clockwise to increase, or
anticlockwise to decrease.
• Always count
anticlockwise turns from the fully
clockwise position.
adjuster
1
head screwdriver
rebound damping
the number
is
of
