FOREWORD

This handbook contains information on the Triumph Tiger Sport motorcycle. Always store this
owner's handbook with the motorcycle and refer to it for information whenever necessary.
chuw
Warnings, Cautions and
Notes
Throughout
this
owner's
particularly
important
information
presented in the following form:
Warning
This warning symbol identifies special
instructions or procedures, which if not
correctly followed could result in personal
injury, or loss of life.
This caution symbol identifies special
handbook,
instructions or procedures, which, if not
is
strictly observed, could result in damage to,
or destruction of, equipment.
Note:
•
This note symbol indicates points of
particular interest for more efficient
and convenient operation.
Foreword
Caution
1
