C O M B I V E R T
INSTRUCTION MANUAL
Type R6-N
Original manual
Document
Part
20116581
ENG
Power Supply and Regenerative
Version
02
Unit
Size 15/19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COMBIVERT R6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KEB COMBIVERT R6

Summary of Contents for KEB COMBIVERT R6

  • Page 1 C O M B I V E R T Power Supply and Regenerative INSTRUCTION MANUAL Unit Type R6-N Size 15/19 Original manual Document Part Version 20116581...

  • Page 3: Table Of Contents

    3.7.5 Ferrite rings ..........................25 Installation ..................... 26 EMC-compatible control cabinet installation ..............26 Installation instructions ....................26 Connection of the COMBIVERT R6-N ................27 4.3.1 General description of inverter input terminals ..............27 4.3.2 Connection terminals of the R6-N power circuit ..............29 4.3.3 Terminals commutation reactor/ harmonic filter ..............30 Connection Power Unit R6-N ....................31...
  • Page 4 Password input ........................43 Monitoring and analysis parameters ................43 Special adjustments ......................46 Annex A ......................50 Dimension of power supply and regenerative units ............50 DC link capacities of KEB frequency inverters ...............51 Decoupling diodes ......................53 A.3.1 Assignment ..........................53 A.3.2 Dimensions of the decoupling diodes ..................53 Annex B ......................
  • Page 5 Figure 10: EMC-compatible control cabinet installation ............26 Figure 11: General description of input terminals at KEB inverter ...........28 Figure 12: Description of the input terminals of the COMBIVERT R6-N ........29 Figure 13: Terminals / earth handle ..................30 Figure 14: Terminals for commutation reactor / harmonic filter ..........30 Figure 15: Power supply and regenerative operation at inverter current ≤ current of one...

  • Page 6: Preface

    Preface Preface The described hard and software are developments of the KEB Automation KG. The en- closed documents correspond to conditions valid at printing. Misprint, mistakes and technical changes reserved. Information on special measures The used pictograms have following significance: Is used, when death or serious bodily injury may be the consequence Danger of non-observance of the measure.

  • Page 7: Validity And Liability

    KEB Automation KG. Copyright The customer may use the instruction manual as well as further documents or parts from it for internal purposes. Copyrights are with KEB Automation KG and remain valid in its entirety.

  • Page 8: Specified Application

    The used semiconductors and components of the KEB Automation KG are developed and di- mensioned for the use in industrial products. If the KEB COMBIVERT F5 is used in machines, which work under exceptional conditions or if essential functions, life-supporting measures or an extraordinary safety step must be fulfilled, the necessary reliability and security must be ensured by the machine builder.

  • Page 9: Abnormal Operation

    At factory setting the modulation is switched off in case of a net phase failure and error mes- sage E.nEt is displayed. Special adjustments from KEB are necessary if the modulation and/or the standard operation should start again within a defined time in case of return of power supply. Product description This instruction manual describes the power supply and regenerative unit KEB COMBIVERT R6-N.

  • Page 10: Part Code

    Preface Part code 1 9 R 6 N 3 E - 9 0 0 A Type A: Standard B: Flat rear D: ext. fan power supply E: Special fan Design 0: Standard reserved 0: Standard 1: modified standard (increased overload) Voltage 9: 3-ph.; 180…550 V; AC Housing 0: without Options...

  • Page 11: Safety Instructions

    COMBIVERT R6 power supply and regenerative units contain dangerous voltages which can cause death or serious injury. COMBIVERT R6 can be adjusted by way that energy is regenerated into the supply system in case of power failure at regenerative operation. Therefore a dangerous high tension can exist in the unit after switching off the supply system.

  • Page 12: Transport, Storage And Installation

    Warning Protect Against Accidental Contact The COMBIVERT R6 must be protected against invalid loading. Components and covers must not be bent or moved as this may affect insulation distances. The units contain electro- static sensitive devices which can be destroyed by inappropriate handling. For that reason the contact of electronic devices and contacts is to be avoided.
  • Page 13 This is permissible in compliance with the standard, since all inverters are given a high voltage test in the end control at KEB. In the case of special requirements please contact KEB.
  • Page 14 Safety Instructions Caution Prevent malfunctions A trouble-free and safe operation of the COMBIVERT R6 is only guaranteed when the con- nection instructions below are strictly followed. Incorrect operation or damage may result from incorrect installation: • Pay attention to mains voltage.
  • Page 15 Attention Cyclic activation and deactivation With applications requiring the COMBIVERT R6 to be switched on and off cyclically, main- tain an off-time of at least 5 min. If you require shorter cycle times please contact KEB. Switching off during the initialization phase can cause undefined conditions. Attention RCD (residual current operated circuit-breaker) When using systems with RCD, the instructions or the requirements of VDE 0100 -T 530 (IEC 60364-5) must be observed.

  • Page 16: Emc Instructions

    EMC instructions EMC instructions COMBIVERT R6-N represent electrical equipment designed for use in industrial and com- mercial units. In accordance with the EMC directive 2006/108/EC, it is not obligatory to mark these devices as they represent components to be further processed by the respective ma- chine and unit manufacturer and are not operable independently according to the EMC di- rective.

  • Page 17: Technical Data

    If the DC infeed current > 85 A DC use two by two of the DC terminals (++ and --) to meet the requirements of the UL standard. The connection cables are parallel connected. Please contact KEB for higher values. After consultation KEB IT and delta power system (see also safety instructions, voltage with respect to ground)

  • Page 18: Special Unit Peak Power

    If the DC supply current > 85 A DC use two by two of the DC terminals (++ and --) to meet the require- ments of the UL standard. The connection cables are parallel connected. After consultation KEB IT and delta power system (see also safety instructions, voltage with respect to ground)

  • Page 19: Overload (Ol) Function

    Technical Data Warning General instructions • Voltage stabilization must be activated at the frequency inverter if a harmonic filter is used. • The units are not short-circuit proof without corresponding dimensioned fuses. • Exceeding of the max. rechargeable DC link capacity can lead to a defect. • A load removal in the DC link circle may be done only after the message „ready“. If the control release is set when switching off the mains, this can lead to an overcurrent error and the •...

  • Page 20: Operating Conditions

    Technical Data Operating conditions Standard Class Instructions EN 61800-2 Inverter-product standard: Rated specifications Definition acc. EN 61800-5-1 Inverter-product standard: General safety max. 2000 m above sea level Site altitude With site altitudes over 1000 m a derating of 1 % per 100 m must be taken into consideration. Ambient conditions during operation extended to -10…45 °C (with temperature over 45°C to max.

  • Page 21: Accessories

    15Z1C04-1000 max. overload 125% 19Z1C04-1000 max. overload 140% Harmonic filter regenerative / 150% motoric regenerative / 150% motoric (no UL certification) Please contact KEB for further sizes and data to the THD value at regenerative operation in accordance with EN 61000-2-12. Harmonic filter (with UL cer- 17Z1C05-1000 21Z1C05-1000 tification)

  • Page 22: Dimensions And Weights

    Dimensions and weights Dimensions and weights 3.7.1 COMBIVERT R6-N Ø F Housing Weight 5.6 kg C1 with operator Figure 3: Dimensions and weights for the COMBIVERT R6-N 3.7.2 Commutation reactor Ø Part number Weight 15Z1B04-1000 72.5 4.4 kg 19Z1B04-1000 12.0 kg 20Z1B04-1000 12.0kg...

  • Page 23: Radio Interference Filter

    Dimensions and weights 3.7.3 Radio interference filter Part number Weight 14E6T60-3000 1.25 kg Figure 5: Radio interference filter 14E6T60-3000 Part number Weight 16E6T60-3000 1.8 kg Figure 6: Radio interference filter 14E6T60-3000...

  • Page 24: Figure 7: Radio Interference Filter 14E6T60-3000

    Dimensions and weights Part number Weight 18E6T60-3000 3.9 kg Figure 7: Radio interference filter 14E6T60-3000 Part number Weight 20E6T60-3000 5.0 kg Figure 8: Radio interference filter 14E6T60-3000...

  • Page 25: Fuse Holder With Cover

    Dimensions and weights 3.7.4 Fuse holder with cover Dimensions: 4,96" 126 mm 1,57" 40 mm 1,34" 34 mm 0,5" 13 mm 0,75" 19 mm 3,15" 80 mm 0,12" 3 mm 1,81 " 46 mm 2,91" 74 mm 0,26" 6,5 mm 0,6"...

  • Page 26: Installation

    EMC sub-mounted filter (<=size 19 R6-S) If necessary, external voltage limi- tation / synchronisation 150 mm Commutation reactor / harmonic 150 mm filter COMBIVERT R6 if necessary, external DC fuses Frequency inverter 150 mm DC lines with ferriteDC- 30 mm 150 mm...

  • Page 27: Connection Of The Combivert R6-N

    Connection of the COMBIVERT R6-N Connection of the COMBIVERT R6-N 4.3.1 General description of inverter input terminals Caution Starting current limiting When connecting inverters to a DC bus pay attention to the internal wiring of the DC volt- age inputs ! Inverters that directly output the DC link bus to the DC terminals must be integrated into the DC bus by way that the supply unit(s) limit the starting current.

  • Page 28: Figure 11: General Description Of Input Terminals At Keb Inverter

    DC link inverters must have an own current is externally limited. capacity. starting current limiting at the DC voltage input. The maximum charging current is taken into account. Figure 11: General description of input terminals at KEB inverter...

  • Page 29: Connection Terminals Of The R6-N Power Circuit

    4.3.2 Connection terminals of the R6-N power circuit Info Input voltage The COMBIVERT R6-N in E-housing is suitable for rated voltages of 230 V and 400 V. The regenerative unit checks the mains at the first switching on and adjusts the parameters accordingly (see parameter CP.31 if mains supply is changed). Attention View of power supply and regenerative units The terminals of a power supply and regenerative unit can be input or output dependent on the actual operating status (power supply or regeneration).

  • Page 30: Terminals Commutation Reactor/ Harmonic Filter

    Connection of the COMBIVERT R6-N Housing Size E Tightening torque [Nm] Name permissible line cross section Function 3-phase supply input of max. 1.5…25 mm² the commutation reactor (AWG 16…4) DC voltage output with starting current limiting Connection for shield- ing/grounding occurs...

  • Page 31: Connection Power Unit R6-N

    L2’ L2.1 L2.2 L3’ L3.1 L3.2 - -/ - -/ Mains fuse type gR COMBIVERT R6-N with DC fuses Frequency inverter (FI type A1…C2 possi- Line contactor with protec- DC fuses type aR/gR 1) 2) ble) tive wiring Radio interference filter E6 DC fuses type aR/gR...

  • Page 32: Power Supply And Regenerative Operation At Inverter Currents ≤ Current Of One R6-N

    (FI type A1…C2 possible) If the inverter current > current of the COMBIVERT R6-S it must be wired at an external terminal (6). The cable cross-section may not be smaller than 10 mm². It must be dimensioned for the DC rated current of the load.

  • Page 33: Regenerative Operation With Decoupling Diodes

    1A Contactor with protec- Choke (xxZ1F04-1010) 11 Frequency inverter (type A1, A2, tive wiring C1, C2) Main fuses COMBIVERT R6-N with DC 12 Frequency inverter (type A1, A2 fuses -> 4.3.1) Mains fuse type gR Decoupling diodes (see annex) 13 Ferrite (optional)

  • Page 34: Figure 18: Regenerative Inverter Currents ≤ Inverter Current (Type A1/A2)

    Regenerative contractor Choke (xxZ1F04-1010) 11 Frequency inverter (all types) with protective wiring Main fuses COMBIVERT R6-N with DC fuses 12 Frequency inverter (type B1, B2) Mains fuse type gR Decoupling diodes (see annex) 13 Ferrite (optional) Radio interference filter E6 9...

  • Page 35: Figure 19: Regenerative Inverter Currents ≤ Inverter Current (Type B1/B2)

    Connection Power Unit R6-N Connection clockwise rotating field required! A load draw from the DC circuit may be done only if the ready signal is active. In case of failure the line contactor must disconnect the units from the supply system. Figure 19: Regenerative inverter currents ≤ inverter current (type B1/B2)

  • Page 36: Regenerative Operation At Parallel Operation Of Up To Two R6-N With Decoupling Diodes

    Otherwise there are fuses in the DC circuit (10) necessary The indicated maximum protection for the connected frequency inverter must be observed! If the inverter current > current of the COMBIVERT R6-S it must be wired at an external terminal (12). The contactor may only be connected if the precharging in the DC circuit is completed. Note the per-...

  • Page 37: Figure 20: Regenerative Operation At Parallel Operation

    A load draw in the DC circuit may be done only when the message „ready“ is set. This can be guaranteed by a series connection of relay R1 of the R6-N units with the control release of the connected inverters. G1, G2 Regenerative unit COMBIVERT R6 Control terminal strip Relay 1 / NO contact...

  • Page 38: Connection Of The Control Board Version N

    *) The relay outputs must be operated with max. 48 V DC protective separation voltage to guarantee the CE standard. After consultation with KEB, a current of max. 2 A AC is per- missible for 120 V AC (depending on the switching capacity etc.).

  • Page 39: Assignment Of The Sockets X2D

    IGBT off → SLAVE active → High IGBT on → High IGBT on → SLAVE active → Attention at parallel connection At parallel connection the regenerative units are connected with the KEB catch cable (see Chapter Accessories) via the socket X2D.

  • Page 40: Wiring Example

    Connection of the control board version N 4.5.3 Wiring example Attention In order to prevent a malfunction caused by interference voltage supply on the control in- puts, the following directions should be observed: • Use shielded/drilled cables • Lay shield on one side of the inverter onto earth potential Lay control and power cable separately (about 10...20 cm apart);...

  • Page 41: Operation Of The Unit

    COMBIVERT R6-N is in status „rEGEn” or „Stb”. Status „Stb“ COMBIVERT R6-N detects a typical voltage level in the DC link circuit of the connected fre- quency inverter (motor operation) and keeps the modulation signals of the regenerative unit deactivated.

  • Page 42: Parameter Summary

    Parameter summary Parameter summary The CP-Parameters are one of the parameter selection defined by KEB. You need an appli- cation manual in order to get access to the entire parameters. Dis- Parameter Setting range Resolu- Factory based play tion setting CP.00 password input 0…9999 – Ud.01 CP.01 inverter state – – – ru.00 CP.02 actual line frequency –...

  • Page 43: Password Input

    – Ud.01 Ex works the COMBIVERT R6-N is supplied without password protection, i.e. all changea- ble parameters can be adjusted. After parameterizing the inverter can be secured against unauthorized access (locking: 100 and release: 200). The adjusted mode is stored.

  • Page 44: Cp.02 Actual Line Frequency - 0.1 Hz

    After switching on, the actual mains frequency is determined during the initialization phase. Slowly changes of the line frequency during the operation are recognized and displayed in CP.02. CP.02 displays the actual regenerative frequency, if the COMBIVERT R6-N is in "netof" state.

  • Page 45: Cp.07 Peak Dc Utilization

    CP.07. The peak value memory can be cleared by pressing the UP and DOWN key or via bus by writing any value you like to the address of CP.07. Switching off COMBIVERT R6-N also clears the memory. Name Enter based on CP.08...

  • Page 46: Special Adjustments

    – ru.39 Resolution Meaning The permanent load of the COMBIVERT R6-N can be evaluated with this parameter, in order to avoid an E.OL error (in-time load reduction). Error E.OL is released, if the overload counter reaches 100 %. Name Enter based on CP.13...

  • Page 47: Cp.18 Anout1 Gain ±20.00

    Special adjustments Name Enter based on CP.18 ANOUT1 gain – An.33 The analog output displays the difference between actual supply frequency and set supply frequency. At factory setting of CP.18 this corresponds to 1 V per 0.1 Hz difference. The dis- play occurs with right sign.

  • Page 48: Cp.21 Last Error

    Depending on the supply system the COMBIVERT R6-S adjusts internally certain parameter values. If the COMBIVERT R6-N is connected to another supply system, these stored parameter values are not valid any longer. Error message "power unit changed (E.Puch)" is displayed.
  • Page 49 Special adjustments Name Enter based on CP.33 operating mode Pn.19 This parameter determines the master or slave of regenerative units at parallel connection. Further it is adjusted whether a harmonic filter or a commutation choke is series-connected. Single units must be adjusted to master. Value range Meaning Master with commutation reactor Master with harmonic filter Slave with commutation reactor Slave with harmonic filter Master-Slave with commutation reactor input selection Master-Slave with harmonic filter input selection...

  • Page 50: Annex A

    Annex A Annex A Dimension of power supply and regenerative units Dimensioning of the power supply and regenerative unit Bridge over ext. load-shunt with Acquire: onlyregeneration ? CZK_all > CZK_max contactor (special ZK_all unit) Acquire: Decoupling R6-N (see 4.4.3 to , t1, T, η...

  • Page 51: Dc Link Capacities Of Keb Frequency Inverters

    Annex A DC link capacities of KEB frequency inverters Frequency inverter F5 200 V units 400 V units Housing size Capacity Housing size Capacity 780 µF 180 µF 880 µF (940 µF*) 180 µF (300 µF*) 1080 µF 300 µF 1080 µF...
  • Page 52 Annex A Frequency inverter G6 Housing Unit size Capacity / µF Precharging circuit Type A1 Type A1 Type A1 Type A1 1120 1035 1400 Type B1 1985 Frequency inverter S6 Housing Unit size Capacity / µF Precharging circuit Type A1 Type A1 Ferrites at the input and output are required in any case when using Attention...

  • Page 53: Decoupling Diodes

    Annex A Decoupling diodes Use decoupling diodes when using the R6 as regenerative unit only, to avoid that the con- nected inverters cannot be supplied via the regenerative unit. Appropriate decoupling diodes are defined for the different sizes. A.3.1 Assignment R6-N Material number Type Volume Ta [°C] Th [°C] Rha [K/W]...

  • Page 54: Figure 23: Dimensions Of The Decoupling Diodes

    Annex A Material number Connection Dimensions 0090147-4101 1 (anode) 2 (cathode) 3 (anode) 1 (cathode) 0090147-6009 3 (anode) 2 (cathode) Figure 23: Dimensions of the decoupling diodes...

  • Page 55: Annex B

    B.1.2 UL Certification Acceptance according to UL is marked at KEB power supply and regener- ative units with the adjacent logo on the type plate. To be conform according to UL for the use on the North American Market the following in- structions must be observed (original text of the UL file in English): •...
  • Page 56 • Following external DC fuses need to be installed in accordance with wiring diagrams in chapter 4.4 for following units without internal DC fuses: 15R6N1E-xxxx Rated 690 Vac / 700 Vdc 50 A (KEB No.: 009025H-3459): R/C (JFHR2) - Type Sitor 3NE8-717-1, manufactured by Sie- mens or Type 170M1364-1, manufactured by Bussmann 19R6N1E-xxxx Rated 690 Vac / 700 Vdc 125 A (KEB No.: 009025H-3559):...
  • Page 57 Notes...
  • Page 58 Notes...
  • Page 59 Notes...
  • Page 60 +39 02 3353531 • fax: +39 02 33500790 net: www.keb.de • mail: kebitalia@keb.it KEB Power Transmission Technology (Shanghai) Co.,Ltd. No. 435 Qianpu Road, Chedun Town, Songjiang District, KEB Japan Ltd. Shanghai 201611, P.R. China 15–16, 2–Chome, Takanawa Minato-ku fon: +86 21 37746688 • fax: +86 21 37746600...
