Technical Specifications

TP-873XR
Input HDMI
Output DGKAT 2.0
Port RS-232
IR
TP-874XR
Input DGKAT 2.0
Output HDMI
Port RS-232
IR
General
Video Max Bandwidth
Max Resolution
Compliance
Extension Range Standard Compression
Level
High Compression
Level
Compliance
Extended RS-232 Baud Rate
Extended IR Frequency
Direction
Controls Front Panel
Rear Panel
Power Source
Consumption
Environmental Operating Temperature
Conditions
Storage Temperature
Humidity
Regulatory Safety
Compliance
Environmental
Enclosure Size
Type
Cooling
General Net Dimensions
Shipping Dimensions
Net Weight (each)
Shipping Weight
Accessories Included
Specifications are subject to change without notice at
TP-873XR / TP-874XR – Technical Specifications
On a female HDMI connector
On a female RJ-45 connector
On a 3-pin terminal block connector for serial link extension
On a 3.5mm mini-jack connector for IR link extension
On a female RJ-45 connector
On a female HDMI connector
On a 3-pin terminal block connector for serial link extension
On a 3.5mm mini-jack connector for IR link extension
Up to 18Gbps (6Gbps per graphic channel)
Standard compression
level
High compression level
HDCP 2.2, HDR 10
Up to 35m (110ft) at 4K@60Hz (4:4:4); Up to 70m (230ft) at
4K@60Hz (4:2:0) or full HD (1080p @60Hz 36bpp)
When using shielded UNIKAT cables:
Up to 50m (160ft) at 4K@60Hz (4:4:4); Up to 70m (230ft) at
4K@60Hz (4:2:0) or full HD (1080p @60Hz 36bpp)
When using plenum HDKat cables:
Up to 40m (130ft) at 4K@60Hz (4:4:4); Up to 50m (160ft) at
4K@60Hz (4:2:0) or full HD (1080p @60Hz 36bpp)
DGKat 2.0
300 to 57600 baud
20kHz to 100kHz
Bidirectional (IR sensor or emitter)
IN, OUT and ON LED indicators
DIP-switches
12V DC, 2A
TP-873XR TP-874XR
and
providing power to the other device ): 12V, 0.87A
0° to +40°C (32° to 104°F)
-40° to +70°C (-40° to 158°F)
10% to 90%, RHL non-condensing
CE
RoHs, WEEE
Tool
Aluminum
Convection ventilation
12cm x 7.2cm x 2.4cm (4.7" x 2.8" x 0.94") W, D, H, each
15.7cm x 12cm x 8.7cm (6.2" x 4.7" x 3.4") W, D, H
0.25kg (0.6lbs) approx.
0.68kg (1.5lbs) approx.
1 Power adapter, 1 power cord and 1 bracket set per device
www.kramerav.com
Kramer Electronics Ltd.
4096x2160@60Hz (4:4:4) 24bpp
3840x2160@60Hz (4:4:4) 24bpp
(one device is connected to power,
