QUANTUM™ LX CONDENSER/VESSEL CONTROL PANEL
090.560-M (APRIL 13)
MAINTENANCE
Page 57
USB Memory Stick Plug-in locations
This version of the LX has a
This drawing represents one version of the LX where
USB connector located on the
the USB stick plugs into the mother board with the
daughter board, no adapter is
use of an adapter.
required.
Q4 USB Location
Q5 USB Locations
