Command access MLRK1-HAG Insert Instructions page 5

7.
Remove dogging assembly and place aside.
9.
Remove push pad end cap
11.
Release push pad and line up holes on baserail
with holes on motor mount underneath.
U S C U S T O M E R S U P P O R T 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | W W W . C O M M A N D A C C E S S . C O M | C A C U S T O M E R S U P P O R T 1 - 8 5 5 - 8 2 3 - 3 0 0 2
CONTINUED
8.
Remove (2) screws from back of the push pad.
10.
Depress the push pad to extend dogging hole.
Slide motor mount attaching hook into
dogging hole.
12.
Install the provided (2) screws and washers with the
allen wrench to secure the motor moun to the baserail.
1
1
2
2
5
