This chapter contains general information and detailed specifications of the eBOX625-842-FL.
The Chapter 1 includes the following sections:


General Description

 System Specification
 Dimensions

I/O Outlets
 Packing List
 Model List
1.1 General Description
The eBOX625-842-FL is an embedded system that supports onboard quad core
Intel® Celeron® J1900 (2.0 GHz) single chip design to provide W indows 8.1,
W indows 7 , W indows 8 Embedded, W indows 7 Embedded or Linux, suitable for the
most endurable operation. It features fan less design with full feature I/O, one 204 -
pin unbuffered SODIMM socket for singe channel DDR3 L-1066/1333 MHz memory,
and enhanced system dependability by built-in W atchdog Timer.
 Features
®
1. Intel Celeron® 2.0 GHz quad core SoC
2. Maximum to 8GB DDR3L-1066/1333 memory for J1900
3. Ultra slim and compact design
4. VGA & HDMI for display output
5. Supports 4 USB 2.0 ports
6. Supports 2 RS-232/422/485
7. Supports 8-CH Programmable Digital I/O
8. Supports dual 10/100/1000Mbps Ethernet ports
One 2.5" SATA HDD drive bay
9.
10. One Full-Size Mini PCI Express Mini Card w/mSATA supported
11. One Half-Size Mini PCI Express Mini Card
12. One SIM slot
13. Watchdog timer
14. 12V / 36W AC-DC Adapter
15. Wide temperature: -20°C~55°C supported
 Reliable and Stable Design
The eBOX625-842-FL adopts the advanced cooling system and supporting the mSATA
device, which makes it especially suitable for vibration environments, best for industrial
automation, digital signage and gaming application.
 Embedded O.S. Supported
The eBOX625-842-FL not only supports Windows 8.1, Windows 7, but also supports
embedded OS, such as Windows 8 Embedded, Windows 7 Embedded, WinCE and
Linux.
 Various Storage devices supported
For storage device, the eBOX625-842-FL supports one 2.5" SATA storage drive bay and
mSATA supported.
