GEEETECH
Square nut
M3 X 16 Screw
M3 X 12 Screw
Spacer
M3 washer
Knob
Step1. Assemble the LCD frame and support plate together, screw up with M3 X 16
Screws and M3 square nuts.
www.geeetech.com Tel: +86 755 2658 4110 Fax: +86 755 2658 4074 ‐ 858
ShenZhen GETECH CO.,LTD
14
4
19
4
18
4
34
4
5
8
55
1
