1.1 Motor end assembly
Name
Stepper motor
Pulley
Motor holder
Motor holder
support
Square nut
M3 X 12 Screw
M3 X 16 Screw
M3 washer
www.geeetech.com Tel: +86 755 2658 4110 Fax: +86 755 2658 4074 ‐ 858
ShenZhen GETECH CO.,LTD
Chapter1 Base Assembly
Part NO.
qty
53
3
33
3
A3
3
A4
6
14
6
18
12
19
6
5
18
Pic
