Start Here
Installing your Microtek ArtixScan DI 3130c
Unpack Contents
Unpack your scanner package and check for
major components.
1. ArtixScan DI 3130c scanner
2. Document feed tray
3. Hi-Speed USB cable
4. Software CDs/DVDs
5. Card Holder
6. Power adapter
7. Power cord
Install Software
Important: You must install software before
connecting your scanner.
Always close any open programs and turn off
Anti-virus utilities before installing software.
A. Turn on your computer.
B. Place the Microtek Software CD/DVD into a drive, and follow the on-screen
instructions to install the scanner driver and software.
C. Restart your computer at the end of all software installation.
NOTE: If the Microtek Software Installer screen does not come up automatically, double-click the
following in succession: "My Computer"; the CD/DVD-ROM icon; then cdsetup.exe to start the
installer program.
Copyright © 2016 Microtek International, Inc. http://www.microtek.com
I49-005049 A, June 2016
1
3
4
1
2
5
6
7

Advertisement

loading
Need help?

Need help?

Do you have a question about the ArtixScan DI 3130c and is the answer not in the manual?

Questions and answers

Related Manuals for Microtek ArtixScan DI 3130c

Summary of Contents for Microtek ArtixScan DI 3130c

  • Page 1 C. Restart your computer at the end of all software installation. NOTE: If the Microtek Software Installer screen does not come up automatically, double-click the following in succession: “My Computer”; the CD/DVD-ROM icon; then cdsetup.exe to start the installer program.
  • Page 2 Install the Document Feed Tray Before using the Document Feed Tray with your scanner, you need to install it on the scanner. Follow the instructions and graphs below to correctly install the Document Feed Tray. A. Lift up the Release button in the direction of the arrow shown to open the scanner cover.

  • Page 3: Connect Scanner

    Customize the Function Button The ArtixScan DI 3130c is equipped with one Select and one Enter buttons, used to automate a number of customized and predefined operations, such as scanning to a file, sending an image to your printer, scanning for OCR, etc. Customizing is done through the Scanner Button Settings interface in the ScanWizard DI, refer to the scanner’s User’s Manual for more details.

  • Page 4: To Load A Stack Of Documents

    Position Documents The scanner supports scanning of document in various materials, such as A4 printouts, insurance papers, legal documents, postcards, credit cards, business cards, and etc. A stack of up to 100 sheets can be fed in the scanner’s Document Feed Tray. Paper sizes can range from 2.91” x 2.1” (74 mm x 52 mm) to 8.5” x 65” (216 mm x 1651 mm).
  • Page 5 Position Documents (Cont.) To Load Cards 1. Slide the Guide Arms toward the center of the feed tray and free up the enough space to put the Card Holder. Guide Arms Card Holder 2. To install the Card Holder into the feed tray, with its front side up, slide the Card Holder along the sides of the Guide Arms down until it completely hangs on...

  • Page 6: Basic Scanning

    Basic Scanning 1. Load the document to be scanned into the document feed tray of the scanner. WARNING: Do not place photo paper or fragile sheets of paper on the feed tray, as doing this will damage the original photo or frail papers during the feeding process. 2.
  • Page 7 13. Click the Open Folder button to locate the scanned images if you want to view. NOTE: For more details on other scanning scenarios applicable to your scanner, refer to the scanner’s User’s Manual in the Microtek Software CD/DVD.
  • Page 8 File Location menu box Click on a thumbnail image to enlarge it in the Image View Window at the right side of the interface. AP control panel (Main interface) TWAIN driver control panel (Scan Setup interface)

  • Page 9: Fixing Paper Jams

    Fixing Paper Jams 1. Lift up the Release button in the Release button direction of the arrow shown to open the scanner cover. Scanner cover 2. Remove the jammed paper by taking out it in a forward-moving direction. 3. Close the scanner cover. You would hear a click sound when the scanner cover returns to its original position.
  • Page 10 Hi-Speed USB cable from the back of your computer, and refer to the installation instructions in this guide or the ArtixScan DI 3130c User’s Manual. 3. When trying to scan, an error message appears on your screen that reads, “Can’t Find Scanners”.
  • Page 11 Finally, select and click the title of the manual you wish to view. manual you wish to view. Missing Items If your package is missing items, please call the Microtek Customer Service Department. Drivers & Software Upgrades After you finish the installation of software, if you found that the installed drivers and software cannot run your product or your computer system properly later, please go to the Microtek Download Service site at ww7.microtek.com.tw/service.php to download and...
