3.3 The Gas connection

After the "NEARBOX" has removed from the of the back of the fire, you can place it loosely
on the ground in proximity to the opening provided in the wall of mantelpiece. The device
is always connected with an approved gas tap 1/2, and preferably with a yellow gasflexible
that is reachable at all times. Provide the mantelpiece with a door so that the valve and
the electrical connection is easily accessible.
GAS SUPPLY TO MAIN BURNER ( RED)
Opening provided in wall
for maintenance
Flexibel
Connection Gas 1/2" (provide tap)
Gas provider

3.4 Electrical connection

These appliances are equipped with a radiographic remote control, making an earthened
220V socket necessary. You should bear in mind that the appliance must be connected to all
electrical supplies for the purposes of service. It's obligatory to connect an earth current.

3.1.5 Modification natural gaz to propane

Modification of the fireplace can only be done by the manufacturer or an approved
installer. A new signal plate is provided.
Instructions for installation and use - Venus True Vision Gas
230V
flexible for GAS
GAS SUPPLY TO SIDE BURNER OR SECOND
BURNER (YELLOW)
Cable to ionistation pin
NEARBOX
True Vision is provided with
a direct ignition , no starting
pilot
Valve 1/2"
