LUNA GAS DIAMOND GAS
550V-550DV-850V-850DV-1150V
INSTRUCTIONS FOR INSTALLATION AND USE
02-2017
Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIAMOND Gas 550V and is the answer not in the manual?

Questions and answers

Related Manuals for M Design DIAMOND Gas 550V

Summary of Contents for M Design DIAMOND Gas 550V

  • Page 1 LUNA GAS DIAMOND GAS 550V-550DV-850V-850DV-1150V INSTRUCTIONS FOR INSTALLATION AND USE 02-2017 Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 2 WARRANTY. IF THIS WILL BE NOT OBSERVED, THE WARRANTY FELL. YOU CAN RELY ON M-DESIGN TO MAKE THIS CHECK FOR YOU, OR YOU CAN DO THIS BY YOURSELF AND FOLLOW THE METHOD BELOW. Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...

  • Page 3: Table Of Contents

    11. SAFETY, ADVICE AND MAINTENANCE ......12. GUARANTEE ..............13. REMOTE CONTROL ............28-30 14. 4-SIDED FRAME (FINISHING EXAMPLES) ......31-33 15. DRAWINGS ................ 34-38 16. IDENTIFICATION BOARDS ..........39-40 17. CE CERTIFICATION ............41-43 Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 4 Push it upwards with your fingers. the window can now be opened. CLOSING To close, push the door gently (but not to soft) against the hooks. Make sure that all hooks are hooked Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...

  • Page 5: General Remarks

    This appliance has been programmed and factory sealed. The sealed parts cannot be modified. The appliance may therefore also be installed in airtight accommodation and accommodation equipped with mechanical ventilation. It constitutes ambient heating even in accommodation equipped with a closed ventilation system. Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...

  • Page 6: Installing The Fireplace

    The maximum height as from the ground to the 4th side frame is 45 cm for LUNA DH and max 35cm for Luna CL/CR/DC pic. 2 pic. 1 A min = 3,5 cm B = 19 cm C min = 22.5 cm Pic 3 Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...

  • Page 7: Nearbox (Gasunit)

    Electro magnet ventil 1 or 2 burners gas connection 1/2” Gas valva Transmitter burner S4965C3029 reciever VK4105ME5004 DFGT-03MC01 V09 NEARBOX FOR 1 BURNER to main burner gas connection 1/2” (455 2 burners) Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...

  • Page 8: The Gas Connection

    GAS SUPPLY TO SIDE BURNER OR SECOND GAS SUPPLY TO MAIN BURNER ( RED) BURNER (YELLOW) 220V Opening provided in wall for maintenance Cable to ionistation pin NEARBOX Connection Gas 1/2” (provide tap) flexible for GAS Valve 1/2” Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...

  • Page 9: Electrical Connection

    It’s obligatory to connect an earth current. 3.1.5 Modification natural gaz to propane Modification of the fireplace can only be done by the manufacturer or an approved installer. A new signal plate is provided. Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...

  • Page 10: Installing The Chimney

    850V / 550V 850DV/550DV/1 150V This is recommanded with a roof exit ≤ 3 m Ø 200/130 Appliance C (min) C (max) Position air inlet 850V / 550V 850DV / 550DV/1 150V Picture 1 Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 11 850DV / 550DV / 1 150V USDHC13 or USDHC10 It is obligatory to use the termination set USSAN with positioning. flex 130mm or 100mm This USSAN piece must be sealed at the roof! Picture 2 Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 12 It is even better, when possible to have a little inclination of 2 or 3 degrees ascending to avoid rain and condenstation in the tube. Install wall outlet like fig 1 Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...

  • Page 13: Flame Adjustment Settings

    After installing the fireplace correctly on the concentric tube or chimney system, you must make a flame adjustment according to the draft (see pagess 9-13 with setting 1-2-3-4). Detail A Flames settings position 1 = Min position 4 = Max Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...

  • Page 14: Insulation And Finishing

    For insulation of the appliance, we advise you to use M Design insulating plates. You are advised against using any other insulation product. Inflammable mate- rials as well may not be used for the finishing.

  • Page 15: Convection Current

    (This phenomenon is very common and can be compared to the gray traces appearing above your radiators.) Optionally you can order design metal lids to cover the inlets and outlets during the summertime . Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 16 7. Technical data for outlet and inlet grids 2xØ150 Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 17 Design grid (outlet) with 2 connections for frontal installation Main Outlet Mirror DRL 2 (488x82) Mirror Masonry Masonry Masonry Mirror Mirror Masonry Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 18 Every opening you make must be connected with a flexible tube dia 150MM (see pic below). This will avoid the heating of the electronic part of the appliance. In this case you will have errorcode F02. Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...

  • Page 19: Mounting A 3 Sided Frame

    ( pic 5 ) and lastly the 4 sided frame ( pic 6 ) picture 5 picture 6 picture 3 picture 4 Attention : Pleas pay attention to leave approx 2 mm inbetween the frame and the finishing material (heat=expansion) Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...

  • Page 20: Positioning The Logs

    To arrange the logs respect the order as follows. Put the big imitation coal pieces around the burner. Put the little imitation coal pieces on the burner and here and there between the Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 21 Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 22 Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 23 Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 24 Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 25 Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...

  • Page 26: First-Time Use

    The appliance must not be used if the door no longer has a window or with the door open. If the window is broken or cracked, the appliance must not be used until the window has been replaced. Contact your M Design reseller. 11. Safety, dvice and maintenance Have your appliance inspected once a year by a qualified technician.

  • Page 27: Guarantee

    Please take good care of your purchase invoice and warranty card and store them in a safe place. SERIAL NUMBER Identification board SERIAL NUMBER : ........... Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...

  • Page 28: Remote Control

    15. This is the maximum flame height. Choose a flame height from 1 to 15 by pressing For all appliances, except for: 850V, 1 150V, 550DV en 850DV Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 29 “b0” , burner 2 goes out. Choose a flame height from 1 to 15 by pressing To switch off the entire stove press Not available for: 700H, 550V, 1000RD en 1300RD Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 30 The fireplace will start-up with 1 or multiple burners depending on the “b” position. Press 2x on the menu button to see whether the fire is set to “0” of “1” position. Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...

  • Page 31: Sided Frame (Finishing Examples)

    1 150 V 1081 1073 Appliance is standard delivered with lower lath 35 mm (4th side frame). The lower lath retracts 5mm into the covering of the fireplace (see X values ) Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 32 X = inside frame measurment (visible dimension) Y = Measured from side down of the lower lath to side up of the upper lath lower lath 3,5cm/4mm Masonry Finishing at side appliance Bench in natural stone Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 33 Y = Measured from side down of the lower lath 850 V/DV to side up of the upper lath 550 V/DV 4 mm = thickness frame 2 mm = expansion joint 1 150 V 1073 1083 Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...

  • Page 34: Drawings

    3.5 cm kader/cadre 4 x Ø150 0 kader/cadre Ø130 frame/Rahme frame/Rahme 7 cm kader/cadre 10.5 cm kader/cadre 773 int. frame/Rahme frame/Rahme Min. 35 mm Max. 450 mm Luna Diamond 850 V Gas/Gaz Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 35 3.5 cm kader/cadre 0 kader/cadre 4 x Ø150 Ø130 frame/Rahme frame/Rahme 7 cm kader/cadre 10.5 cm kader/cadre 773 int. frame/Rahme frame/Rahme Min. 35 mm Max. 450 mm Luna Diamond 850 DV Gas/Gaz Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 36 Luna 550 V gold gas/gaz Ø200 3.5 cm kader/cadre 0 kader/cadre 2 x Ø150 Ø130 frame/Rahme frame/Rahme 473 int. 7 cm kader/cadre 10.5 cm kader/cadre frame/Rahme frame/Rahme Min. 35mm Max. 450mm Luna Diamond 550 V Gas/Gaz Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 37 3.5 cm kader/cadre 0 kader/cadre 4 x Ø150 Ø130 frame/Rahme frame/Rahme 7 cm kader/cadre 10.5 cm kader/cadre frame/Rahme frame/Rahme 473 int. Min. 35 mm Max. 450 mm Luna Diamond 550 DV Gas/Gaz Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 38 3.5 cm kader/cadre 0 kader/cadre 4 x Ø150 Ø130 frame/Rahme frame/Rahme 1165 1073 int. 7 cm kader/cadre 10.5 cm kader/cadre frame/Rahme frame/Rahme Min. 35 mm Max. 450 mm Luna Diamond 1150 V Gas/Gaz 1086 Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...

  • Page 39: Identification Boards

    16. Identification boards Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 40 Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...

  • Page 41: Ce Certification

    17. CE Certification Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 42 Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
  • Page 43 Instructions for installation and use DIAMOND Gas 550V-DV-850V-DV-1150V...
