  • Page 1 VENUS HT / DHT INSTRUCTION FOR INSTALLATION AND USE MONTAGE- UND BEDIENUNGSANLEITUNG Passion for fire...
  • Page 2: Table Of Contents

    SUMMARY INHALT 1. GENERAL ................... 3 ALLGEMEIN ................. 3 1.1 TRANSPORT AND INSTALLATION ........ 3 1.1 TRANSPORT UND MONTAGE ......... 3 1.2 FUEL ..................3 1.2 BRENNSTOFFE ............... 3 1.2.1 Wood 1.2.1 Hol� 1.2.2 Forbidden fuel 1.2.2 Ungeeignete Brennstoffe 1.3 STARTING THE FIRE ............4 1.3 ANZÜNDEN DES FEUERS ..........
  • Page 3: General

    1. GENERAL 1.ALLGEMEIN 1.1 TRANSPORT AND INSTALLATION 1.1. TRANSPORT UND MONTAGE • Transport the VENUS HT in an upright position, or, in encum- • VENUS HT/DHT sollte stehend transportiert werden oder in bering circumstances, at an angle of 45°. Ausnahmefällen in einem Winkel von 45 ° 1.2 FUEL Das Öffnen und Schliessen der Türe : Öffnen Sie die Türe langsam wenn das Feuer brennt.
  • Page 4: Starting The Fire

    1.3 STARTING THE FIRE 1.3 ANZÜNDEN DES FEUERS • Open the window • Öffnen Sie die Feuerraumtüre • Put a bed of tinder (paper or firelighters) with a li�le kindling • Legen Sie kleine Holzstücke oder Anzünder dazu. (small twigs or pieces of wood) in the stove and light the tinder. •...
  • Page 5: Installation

    2. INSTALLATION 2. MONTAGEANLEITUNG 2.1 ACTIONS TO BE TAKEN UPON INSTALLATION 2.1 MONTAGE Your supplier is the specialist who chose to represent M-design in Ihr Lieferant hat sich als Fachmann in Ihrer Region für your area. For M-design entschieden. Zu Ihrer Sicherheit und Zufriedenheit your own safety and satisfaction, we advise you to entrust him with raten wir Ihnen, einen Fachmann mit der Montage zu beauftra- the installation.
  • Page 6: Minimum Height Of The Flue In Terms Of Its Reduction

    2.3.1 MINIMUM HEIGHT OF THE FLUE IN TERMS OF ITS REDUCTION. MINIMUM HÖHE SCHORNSTEINKANAL MIT ANDEREM DURCHMESSER � ₂₅₀ � ₂₀₀ � ₁₈₀ Venus 700 HT ≥ 4m Venus 850 HT ≥ 4m ≥ 6m Venus 1000 HT ≥ 4m ≥...
  • Page 7: Measurments

    2.6 MEASUREMENTS / ABMESSUNGEN VENUS 700HT VENUS 850HT WITH SHORT FRAME / WITH SHORT FRAME / MITT KLEIN RAMH MITT KLEIN RAMH 360° 360° STANDARD 1600mm STANDARD 1550mm WITH LONG FRAME / MITT KLEIN LANG RAMH WITH LONG FRAME / MITT KLEIN LANG RAMH 360°...
  • Page 8 VENUS 850 DHT VENUS 1000HT WITH SHORT FRAME / MITT KLEIN RAMH WITH SHORT FRAME / MITT KLEIN RAMH 360° 360° STANDARD 1500mm STANDARD 1550mm 360° 360° WITH LONG FRAME / WITH LONG FRAME / MITT KLEIN LANG RAMH MITT KLEIN LANG RAMH INSTRUCTION FOR INSTALLATION AND USE VENUS HT - WOOD MONTAGE- UND BEDIENUNGSANLEITUNG VENUS HT UND DHT - HOLZ M-DESIGN...
  • Page 9: Air Supply For Combustion

    2.5 VERBRENNUNGSLUFTZUFUHR 2.5 AIR SUPPLY FOR COMBUSTION Every form of combustion uses air. In the casae of a termally sea- Jede Verbrennung braucht Luft. Im Falle eines thermisch abgeschlossenen Zimmers, ist eine zusä�liche Luf�ufuhr notwendig. Auf jeden Fall sollte man vermeiden einen led room supplementary air supply is essential.
  • Page 10: General Recommendations

    3. ALLGEMEINE EMPFEHLUNGEN 3. GENERAL RECOMMENDATIONS Bevor Sie das Gerät abmauern, muss das Gerät am Abgaskanal The appliance must be connected to the fl ue pipe and tested be- angeschlossen und getestet werden. Für eine optimale Fertigstel- fore the material is cemented in. In order to ensure that the ap- lung sollten der Heizeinsa�...
  • Page 11: Garantee

    4. GARANTIE 4. GUARANTEE 4.1 DAUER UND EINSCHRÄNKUNGEN 4.1 TERMS AND ITEMS COVERED • 7 Jahre Garantie auf die allgemeine Struktur • 7 years’ guarantee on the general structure. • 2 Jahre Garantie auf auswechselbare Ersa�teile und die Regelklappe • 2 years’ guarantee on the parts and on the baffle plate •...
