- Page 1 For de Installer INSTRUCTIONS FOR INSTALLATION RUSTICA TRUE ISION CLOSED GASFIREPLACES Distributor/Manufacturer M-Design Benelux BVBA B-8210 Zedelgem - Belgium V-2020-01...
-
Page 2: Table Of Contents
1. General remarks ................... 3 2. Connection ....................3 3. Installating the fireplace ................4 3.1. Positionning the fireplace ..............4 3.2. The gasunit ..................... 5 3.3. The gas connection ................6 3.4. Electrical connection ................6 3.5. Modification natural gas to propane (or inverse) ........6 4. -
Page 3: General Remarks
1. General remarks This is an appliance using the closed combustion system, designed for the atmosphere and comfort of your living-room. It constitutes an efficient source of heat and gives the impres- sion of a real fire. The balanced flue appliances are based on the principle of natural extraction from the fi- rebox, which eliminates flue gas outside and brings in air (oxygen) from outside the house which is necessary for combustion of the gas. -
Page 4: Installating The Fireplace
3. INSTALLATING THE FIREPLACE 3. INSTALLATING THE FIREPLACE After having checked the appliance, you are ready to install your 3.1. POSITIONNING THE FIREPALCE 3.1. POSITIONNING THE FIREPALCE Place the appliance on a stable surface using the adjustable feet. Adjust the height of the appliance turning the bolt. -
Page 5: The Gasunit
3.2. THE GASUNIT For safety reasons, The gasbattery or “NEARBOX” is furnished in a box with the fireplace reciever DFGT-03MC01 V09 to second burner or side burner to main burner Electro magnet ventil 1 or 2 burners gas connection1/2” Gas valva Transmitter burner VK4105ME5004 Dimensions gasunit : 455 x 188 x Height 64mm... -
Page 6: The Gas Connection
3.3. The Gas connection After the “NEARBOX” has removed from the of the back of the fire, you can place it loosely on the ground in proximity to the opening provided in the wall of mantelpiece. The device is always connected with an approved gas tap 1/2, and preferably with a yellow gasflexible that is reachable at all times. -
Page 7: Installing The Chimney
4. Installing the chimney Install the concentric flue duct as indicated by ONTOP - METALOTERM. The only authorised pipes are ONTOP Metaloterm™. ONTOP-METALOTERM tested our appliances with their conduct and we only guarantee a good working of the appliance with those. Between the external wall of the pipe and the wall or the ceiling, you should allow for a clearance of at least 50mm and protection that is suitable against temperatures of around 130°C. -
Page 8: Roof Exit Via Existing Chimney (C91)
4.2. ROOF EXIT VIA EXISTING CHIMNEY (C91S) seal hermetically on the chimney USDVC13 USSAN 13 USSAN 13 C min = 2m C max = 9m seal hermetically on the chimney USKB US 100/50/25 Ø200/Ø130 USSAN 13 sanitation kit: required when connecting to an existing chemney. This one must be hermetically sealed to the ceiling and the USSAN13 on the top of the chimney must also be hermetically sealed at the exit. -
Page 9: Isolation Et Finition
5. INSLATION AND FINISHING Masonry should be erected around the fireplace with a minimum distance of 4 cm between the fireplace and the finish. It is forbidden to put bricks or any other material on the fire- place. IT MUST BE TOTALLY DETACHED FROM ALL MATERIALS. Now that installation is complete, the unit can be built in. -
Page 10: Contruction Of Interior In Briquettes
7. CONSTRUCTION OF INTERIOR IN BRIQUETTES The interior of the Rustica is rectangular, so you have two solutions, either to build your interior briquettes in a straight way or rounded in the corners reminiscent of the style of old fireplaces. The briquetting must imperatively circumvent the central plate (red zone) to allow access to the burners and hearth. - Page 11 Finish against baffle and side profile Tilting box finishing (4th removable side) Instructions for installation - True Vision Rustica English...
-
Page 12: Mounting Of The Window
8. MUNTING THE WINDOW To protect the glass from breakage, it is supplied separately with the fireplace. We recommend that you mount the window once the unit is fully installed and boxed. Similarly, do not mount the window until you have finished the interior with the briquette decoration. - Page 13 Keep the door open as much as possible and attach the support according to photo 1. Close the door by pushing it down and toward the fireplace at the same time 2. Push the door against the fireplace. 3. The door goes up automatically and will be locked once she takes position behind the folded profile.
- Page 14 9. ASSEMBLY OF THE TILtING BOX If you want to put a strip of bricks in front of the fi- replace, you need to install a tilting box beforehand. Without this device, the glass will break with opening the door The box is a free option and must be requested when ordering Warning: do not install the box on a fireplace already equipped with a window or door...
- Page 15 Use the bolts and nuts (supplied with the fireplace) to attach the box to the fireplace. Use the long bolts (supplied with the fireplace) to level the box with the floor Instructions for installation - True Vision Rustica English...
- Page 16 Important: check the operation of the tilting box At the opening of the door, the tilting pla- Closed door: horizontal tilting plate te is inclined Door fully open: the tilting plate must be slanted as in the picture Instructions for installation - True Vision Rustica English...
-
Page 17: Woodset
10. WOODSET TRUE VISION RUSTICA WARNING: Do not put anything on the ignition stem and in the rectangular area. In case the fire is not burning in first ignition after arranging of logs set, please open the window on the device and check if the electrode is clear and also the rectangular area around electrode is clear too. - Page 18 Slide block 3 (with hole) on the flexible burner Slide block 2 (with hole) on the flexible burner Slide block 4 (with hole) on the flexible burner Lay imitioation coal as in the picture Put the glass wool on the “angel’s hair” block 5 block 7 and 8 block 6...
- Page 19 block 9 (behind the window) and block 10 in front of the window (outside the fireplace) Instructions for installation - True Vision Rustica English...
- Page 20 SET H1 : SMALL 3 pakjes imitatiekolen / 3 sachets immitation charbon / 3 bags of charcoal immitation / 3 Beutel Holzkohleimitation gat/trou/hole gat/trou/hole Instructions for installation - True Vision Rustica English...
- Page 21 Instructions for installation - True Vision Rustica English...
- Page 22 SET H2 : SMALL 3 pakjes imitatiekolen / 3 sachets immitation charbon / 3 bags of charcoal immitation / 3 Beutel Holzkohleimitation gat/trou/hole gat/trou/hole Instructions for installation - True Vision Rustica English...
- Page 23 Instructions for installation - True Vision Rustica English...
- Page 24 RUSTICA SMALL Met LED / avec LED / With LED / Mit LED As / cendre / ashes Instructions for installation - True Vision Rustica English...
-
Page 25: Dimensions
11. DIMENSIONS XL, L, M Type A(mm) B(mm) C(mm) Rustica M 850-995 800-1100 1311 Rustica L 1000-1175 800-1100 1461 Rustica XL 1180-1360 800-1100 1611 Instructions for installation - True Vision Rustica English... - Page 26 Rustica SMALL Instructions for installation - True Vision Rustica English...
-
Page 27: Spare Parts
12. SPARE PARTS Instructions for installation - True Vision Rustica English...
