3.2 Nearbox (gasunit)

For safety reasons, The gasbattery or "NEARBOX" is fixed with screws on the pallet.
IT IS MANDATORY TO UNSCREW THE BATTERY FROM THE REAR PRIOR TO INSTALLATION .
to second burner or side burner
to main burner
Electro magnet ventil 1 or 2 burners
gas connection1/2"
Dimensions gasunit : 455 x 188 x Height 64mm
Instructions for installation and use - Venus True Vision Gas
B
A
Gas valva
VK4105ME5004
reciever
DFGT-03MC01 V09
Transmitter burner
English
7
