LUNA
700- 1000-1150-1300-1600-1900 H
GOLD GAS
INSTRUCTION FOR INSTALLATION AND USE
Passion for fire
1
English 06-2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUNA 700H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for M Design LUNA 700H

Summary of Contents for M Design LUNA 700H

  • Page 1 LUNA 700- 1000-1150-1300-1600-1900 H GOLD GAS INSTRUCTION FOR INSTALLATION AND USE Passion for fire English 06-2012...
  • Page 2 V E R Y I M P O R T A N T I N S T A L L A T I O N I N S T R U C T I O N S F O R T H E M - D E S I G N G A S F I R E P L A C E S T H E S U P P L I E R T A K E S N O...

  • Page 3: Table Of Contents

    SUMMARY 1. GENERAL REMARKS .............. 2. CONNECTION ................3. INSTALLING THE FIREPLACE ..........3.1.1 Positioning the fireplace ..........3.1.2 Gas connection ..............3.1.3 Electrical connection ............4. INSTALLING THE CHIMNEY ..........8-13 5. INSULATION AND FINISHING ........... 6. CONVECTION CURRENT............14-15-16 7.
  • Page 4 OPEN AND CLOSE THE DOOR CLOSING OPEN IF SOME DUST OR WASTE IS SEEN ON THE WINDOW ( INSIDE AND OUTSIDE ), CLEAN THIS BEFORE THE FIRST USE OF THE FIREPLACE. CLEANING THE WIN- DOW IS THE ONLY MAINTENANCE ACTION THAT CAN BE DONE BY THE CONSUMER INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...

  • Page 5: General Remarks

    1. GENERAL REMARKS This is a moulding of the closed combustion system, designed for the atmosphere and comfort of your living-room. It constitutes an efficient source of heat and gives the impression of a real chim- ney fire. The gas with air-vent furnaces are based on the principle of natural extraction from the furnace, which eliminates flue gas outside and brings in air (oxygen) from outside the house which is neces- sary for combustion of the gas.

  • Page 6: Installing The Fireplace

    3. INSTALLING THE FIREPLACE After having checked the appliance, you ready to install your appliance. This is done as follows 3.1.1 POSITIONING THE FIREPLACE Place the fireplace on a stable surface using the adjustable feet. Adjust the height of the fireplace by turning the bolt ( pic 1 ) The stove may not be placed direct ont the floor to allow natural convection.

  • Page 7: Gas Connection

    3.1.2 GAS CONNECTION The appliances are standard delivered with a 1/2” gas solded connection ( fig. 1 ). It is always located at the left-hand side of the appliance. Make sure nothing remains in the gas lines, since this may easely lead to blockage. An approved gas valve should always be connected to the appliance, wich must be accesible at all time .
  • Page 8 PIC. 1 ROOF EXIT ( C31 ) TAB. 1 This is recommanded with a roof exit > 3m Ø 150/100 Restriction HR+ (as from 4m) Appliance C (min) C (max) 700 H / 1000 H Ø 60 as from 2 m : Ø 75 1150 H Ø...
  • Page 9 PIC. 2 ROOF EXIT VIA EXISTING CHIMNEY (C91) TAB. 1 Ø 150 (min) / Ø 100 Restriction HR+ (as from 4m) Appliance C (min) C (max) 700 H / 1000 H Ø 60 1150 H Ø 60 1300 H Ø 60 1600 H / 1900 H Ø...
  • Page 10 Pic. 3 WALL EXIT (C Ø 150/100 WITH REDUCTION USVK13 ON THE APPLIANCE (FIG. 3 ) Appliance A (min) B (min) B (max) Restriction HR+ 700 H /1000 H 1,25*m wall exit =A+1m Ø 75 1150 H 1,25*m wall exit =A+0,5m Ø...
  • Page 11 Ø 200/130 Appliance A (min) B (min) Restriction HR+ B (max) 700 / 1000 H wall exit Ø 70 A+8m 1150 H wall exit Ø 75 A+7m 1300 H wall exit Ø 75 A+6m 1600 H wall exit Ø 90 A+4m 1900 H wall exit...
  • Page 12 Pic. 5 ROOF EXIT with 90° bends Ø 150/100 WITH REDUCTION USVK13 ON APPLIANCE Aplliance A (min) B (max) C (min) (A+B+C )max 700/1000 H 1,25* m A+C+0,5m B-A-0,5m 1150 H 1,25* m A+C+0,5 B-A-0,5 1300 H 1,25* m 1600 H 1,25* m A+C-0,5m B-A+0,5m...

  • Page 13: Insulation And Finishing

    For insulation of the furnace, we advise you to use M Design insulating plates. You are advised against using any other insulation product. Inflammable materials as well may not be used for the finishing.

  • Page 14: Convection Current

    6. CONVECTION CURRENT Please , follow this instruction. The appliance can overheat if you not apply those instructi- ons. Errorcode F02 will appear ! The enclosure of the furnace must be provided with ventilation grills or openings allowing for the elimination of heat by convection.
  • Page 15 INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...
  • Page 16 YOU HAVE TO CONNECT AT LEAST TWO APPERTURES SITUATED AT THE TOP OF THE APPLIANCE. FOR THE LUNA 1600, YOU MUST CONNECT 4 APPERTURES. THE STOVE MAY NOT BE PLACED DIRECT ON THE STOVE MAY NOT BE PLACED DIRECT ON THE FLOOR, WTHOUT THE FEETS.

  • Page 17: Mounting A 3 Sided Frame

    7. MOUNTING A 3-SIDED FRAME 3-sided frame pic 1 upper frame sideframe 2,25cm 4 sided frame (lower piece) pic 2 Fireplace is delivered standard with 4sided frame 3,5cm, an upper and 2 sideframes ( see pic. 2 ) Before mounting the 3 sided frame, remove 4 sided frame ( lower piece ) by lift it carefully up. Pull out the upper frame and in second way the left and right sideframes.

  • Page 18: Positioning The Logs, Diamond, Sapphire And White Pebbles

    8. PUTTING IN PLACE THE LOGS, DIAMOND, SAPPHIRE AND WHITE STONES • Please check that the pilot light is switched off and that the furnace has cooled down. • Move the window to the front by pulling it. The window tips open at 45°. •...

  • Page 19: 1000H

    INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...
  • Page 20 INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...

  • Page 21: 1150H

    INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...
  • Page 22 INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...

  • Page 23: 1300H

    INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...
  • Page 24 INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...

  • Page 25: 1600H

    INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...
  • Page 26 INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...

  • Page 27: First-Time Use

    After the first few fires, a light deposit may appear on the window. It comes from the paint- work. Once the furnace is cold you can get rid of this deposit by using M Design’s Bio-Clean cleaning product. This product may be used later on for cleaning the window.

  • Page 28: Startpilot

    11. STARTPILOT The M-Design Gas appliance are provided with “Constant startpilot”. After the first use or when the winterperiod is coming and you use the fireplace daily, you must let the startpilot switch ON. Don’t switch it off after each use. This startpilot avoids condensation in the fireplace and protects the whole appliance and even the electronic parts against humidity.
  • Page 29 INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...
  • Page 30 INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...
  • Page 31 INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...
  • Page 32 INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...

  • Page 33: Drawings

    LUNA 700 H GOLD gas connection gas on the left side INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...
  • Page 34 LUNA 1000 H GOLD gas connection gas on the left side INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...
  • Page 35 LUNA 1150 H GOLD gas connection gas on the left side INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...
  • Page 36 LUNA 1300 H GOLD gas connection gas on the left side INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...
  • Page 37 LUNA 1600 H GOLD gas connection gas on the left side INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...
  • Page 38 LUNA 1900 H GOLD gas connection gas on the left side INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...
  • Page 39 INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...
  • Page 40 INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...
  • Page 41 4-sided frame INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...

  • Page 42: Spare Parts

    INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...

  • Page 43: Guarantee

    14. GUARANTEE This page is your warranty card. The guarantee is only valid for faults caused by construction defects or defects in the parts used to build the furnace. M-Design offers a 12 month guarantee on all electronic parts and a 8 year guarantee on the furnace construction.

  • Page 44: Ce Certification

    15. CE CERTIFICATION INSTRUCTION FOR INSTALLATION AND USE - LUNA 700-1000-1150-1300-1600-1900H GOLD - GAS...
