- Page 1 LUNA GOLD+ COLLECTION INSTRUCTION FOR INSTALLATION AND USE Passion for fire English - 08/2011 INSTRUCTION FOR INSTALLATION AND USE LUNA GOLD+ WOOD...
- Page 2 V E R Y I M P O R T A N T I N S T A L L A T I O N I N S T R U C T I O N S F O R T H E M - D E S I G N G A S F I R E P L A C E S T H E S U P P L I E R T A K E S N O...
-
Page 3: Table Of Contents
SUMMARY 1. GENERAL ..................1.1 TRANSPORT AND INSTALLATION ....... 1.2 TYPES OF FUEL ..............1.2.1 Wood 1.2.2 Forbidden fuel 1.3 STARTING THE FIRE ............2. INSTALLATION ................ 2.1 ACTIONS UPON INSTALLATION ........2.2 POSITIONING THE FIREPLACE ........2.3 INSULATION AND FNISHING ........2.4 MOUNTING A 3-SIDED FRAME ........ -
Page 4: General
1. GENERAL 1.1 TRANSPORT AND INSTALLATION • Transport the Luna in an upright position, or, in encumbering circumstances, at an angle of 45°. • The handles for transportation purposes have been attached inside the slots provided on the sides of the Luna (see Pic.1) •... -
Page 5: Starting The Fire
1.3 STARTING THE FIRE • Open the window (pic.3). • Put a bed of tinder (paper or firelighters) with a little kindling (small twigs or pieces of wood) in the stove and light the tinder. • Leave the door slightly ajar (+ 3 cm) to get a turbo stream of air that will make the kindling catch fire. -
Page 6: Installation
2. INSTALLATION 2.1 ACTIONS TO BE TAKEN UPON INSTALLATION Your supplier is the specialist who chose to represent M-design in your area. For your own safety and satisfaction, we advise you to entrust him with the installation. The appliance has to be installed according to certain prescribed rules and local regulations. -
Page 7: Insulation And Fnishing
For insulation of the furnace, we advise you to use M Design insulating plates. You are advised against using any other insulation product. Inflammable materials as well may not be used for the finishing. -
Page 8: Mounting A 3-Sided Frame
2.4 MOUNTING A 3-SIDED FRAME ( see page 23 and 24 drawings 3-si- ded frame and 4th side ) First remove the profile that is delivered with the fireplace ( pic. 1 ) The 3 sided frame consist of 3 parts and are assembled to the Luna ( pic. 2 ) Fixing to frame with the included screws ( pic.3 ) the 3 sides frame and his 3 parts pic.2... -
Page 9: Air Supply For Combustion
2.5 AIR SUPPLY FOR COMBUSTION Every form of combustion uses air. In the case of a thermally sealed room supplementary air supply is essential. One must at all times avoid creating under-pressure in the room. If a cooking hood ap- pears to be absolutely essential in the adjoining room, sufficient air supply will have to be provided to avoid every form of under-pressure. -
Page 10: Convection Current
2.6 CONVECTION CURRENT 2.6.1 Natural convection It is compulsory to open 2 or 4 hot air vents (see table 1) at the top of the appliance. The entrance for the air supply convection are situated at the lower backside of the Luna Gold+ and also through the opening that is provided for the fan. - Page 11 INSTRUCTION FOR INSTALLATION AND USE LUNA GOLD+ WOOD...
-
Page 12: Fan
The grids are provided with two connections. 2 flexibles for one grid ! Two holes between the two connection provides ventillation in the maconry. To simplify the mounting of the grids you can use the corner profile wich is furnished with the grid. This profile is can be mounted on the side of the grid (two little wholes en screws are provided). -
Page 13: Flue
2.8 FLUE 2.8.1 Flue The construction of chimney must comply with strict conditions: All the Luna stoves have a standard flue opening of 250 mm. in diameter. Certain chimney configurations may require different standard diameters. In that case, look at table for the height of the flue and the possibility of reducing the diameter with the help of a reduction piece. -
Page 14: How To Regulate Fireplace In Sense Of Drought
2.9. HOW TO REGULATE FIREPLACE IN SENSE OF DROUGHT 2.9.1 Baffle plate The stoves have all been provided with an automatically adjustable baffle plate. This can be adjusted according to the chimney draught. In this way, all stoves are suited to every chimney and draught. -
Page 15: Second Setting
2.9.1.2 SECOND SETTING : Remove screws to adjust the moving plate nr 1 (fig 9e ) in sence of drough FIG. 9e IMPORTANT : IF YOU THINK THE DROUGHT IS NOT ENOUGH AND YOU HAVE SOME SMOKE RETURN IN THE LIVINGROOM, THEN YOU HAVE TO CHECK FIRST POINTS 2.9.1.1 AND 2.9.1.2. -
Page 16: System With Three Deflectors
2.9.2 SYSTEM WITH THREE DEFLECTORS AND TWO AUTOMATIC VALVES With a closed door (fig 10) , we have a minimal evacuation for the combustion gaz. The main valve is closed (fig.10) The second deflector has a valve too (fig.11). When opening the liftdoor, the main valve and the second valve in the second deflector are opening simultaniously (fig.11). -
Page 17: Secondary Air Flow For Combustion
IMPORTANT : THIS MUST BE DONE IF YOU DIDN’T FOUND SATISFACTION WITH 2.9.1.1 AND 2.9.1.2 Fig.12 Pic..13 ATTENTION : FOT THE LUNA 550V YOU DON’T FIND A PLATE nr 1a AND nr 3. THIS IS BE- CAUSE OF THE NARROW ARCHITECTURE OF THIS MODEL. IN ANY CIRCUMSTANCES THIS WILL NOT GIVE A BAD FUCNTION OF THE APPLIANCE. -
Page 18: Baffle Plate Luna Gold See-Trough
2.10 AUTOMATICALLY ADJUSTABLE DOUBLE PLATE (Luna Gold see-trough ) In the illustrated figure, the first lift door and the first plate will drive the second lift door and second plate. The lift doors have been provided with a mechanical transmission to drive the different plates. -
Page 19: Functionning
3. FUNCTIONNING When burning this fireplace with a closed door, the air clapet with seal is closed and so the fire takes the air through the channel connected with the flexibel from outside. The air is then spread underneath the spoiler over the entire width of the fireplace. It is important to clean out the fireplace from the ashes and to free the space under the spoiler to let the air coming into the fireplace ( Pic.9 ). -
Page 20: General Recommendations
4. GENERAL RECOMMENDATIONS The appliance must be connected to the flue pipe and tested before the material is cemented in. In order to ensure that the appliance functions optimally, one must insulate the hot air ducts completely, comply with the minimum of the diameter measurements for the hot air ducts and hot air vents and the chimney must be adjusted. -
Page 21: Guarantee
5. GUARANTEE 5.1 TERMS AND ITEMS COVERED • 8 years’ guarantee on the general structure. • 2 years’ guarantee on the parts and on the baffle plate • 1 year’s guarantee on the fans and the speed variator. • No guarantee on glass, seals or Chamotflex plates 5.2 PROVISO This contract ceases to be valid if the instructions and guidelines of these operating instructions were not followed. -
Page 22: Spare Parts
6. SPARE PARTS INSTRUCTION FOR INSTALLATION AND USE LUNA GOLD+ WOOD... -
Page 23: Sided And 4Th Frame
7. 3 SIDED FRAME INSTRUCTION FOR INSTALLATION AND USE LUNA GOLD+ WOOD... - Page 24 8. 4th sided Frame INSTRUCTION FOR INSTALLATION AND USE LUNA GOLD+ WOOD...
