1. General remarks

This is an appliance using the closed combustion system, designed for the atmosphere and
comfort of your living-room. It constitutes an efficient source of heat and gives the impres-
sion of a real fire.
The balanced flue appliances are based on the principle of natural extraction from the fi-
rebox, which eliminates flue gas outside and brings in air (oxygen) from outside the house
which is necessary for combustion of the gas. It uses to this effect two concentric pipes.
The internal pipe ensures the elimination of burned gases and the external pipe brings in
combustion air. The advantage of this principle is that the equipment works independently
of the atmosphere which predominates in the house.

2. Connection

This appliance must be connected by an approved installer in accordance with the most
recent
regulations in force. On the basis of your order specifications, this appliance is designed for
natural or propane gas.
Read the instructions before installing and using this appliance. Before installing the appli-
ance, please check the local regulations about this type of appliance (identification of the
type of gas, etc.) and check that the furnace is adapted to your means of installationt.
The appliance must be connected to the type of gas mentioned on the
appliance. Never connect a propane burner to natural gas or vice versa!
It is imperative that the installer sees to the following:
• The appliance must be subject to an air tightness test of the gas and elimination of flue
gases.
• The concentric pipe, if already available, must be working correctly.
• The running of the control valve, lighting of the pilot light, the main burner and the
thermocouple must all be checked. This appliance has been programmed and factory
sealed. The sealed parts cannot be modified.
• The appliance may therefore also be installed in airtight accommodation and accom-
modation equipped with mechanical ventilation. It constitutes ambient heating even in
accommodation equipped with a closed ventilation system.
