  • Page 1 Operator’s Manual vant 9600 ® Avant 9600 ® Digital Pulse Oximeter English 0123...
  • Page 2 9600 Digital Pulse Oximeter. The information in this manual has been checked carefully and is believed to be accurate. In the interest of continued product development, NONIN reserves the right to make changes and improvements to this manual and the products it describes at any time, without notice or obligation.

  • Page 3: Table Of Contents

    Patient Security Mode ............24 Error Codes ................25 Communication ...............26 Memory Features ..............26 Playing Back Memory Data ..........27 Serial Patient Data Outputs ..........28 Using the Avant 9600 with Philips VueLink .....29 Specifications ..............31 Parts and Accessories ............34 Service, Support, and Warranty ........36 Troubleshooting ..............37...

  • Page 4: Guide To Symbols

    Guide to Symbols Guide to Symbols This table describes the symbols that are found on the Avant 9600. Regulatory Symbols Attention: See Instructions for Use or related materials. Type BF Applied Part (Patient isolation from electrical shock). UL Mark for Canada and the United States...

  • Page 5: Precautions For Use

    Do not use a damaged sensor. Do not use the Avant 9600 in or around water or any other liquid when the AC power adapter is used. As with all medical equipment, carefully route patient cables and connections to reduce the possibility of entanglement or strangulation.
  • Page 6 The use of accessories, sensors, and cables other than those listed in this manual may result in increased emission and/or decreased immunity of this device. The Avant 9600 is designed to determine the percentage of arterial oxygen saturation of functional hemoglobin. Significant levels of dysfunctional hemoglobin, such as methe- moglobin, might affect the accuracy of the measurement.
  • Page 7 Portable and mobile RF communications equipment can affect medical electrical equipment. If the Avant 9600 fails to respond as described, discontinue use until the situation is corrected by qualified personnel. Cardiogreen and other intravascular dyes may affect the accuracy of SpO measurements.
  • Page 8 Precautions for Use Manufacturer’s Declaration Refer to the following table for specific information regarding this device’s compliance to IEC Standard 60601-1-2. Table 1: Electromagnetic Emissions Emissions Test Compliance Electromagnetic Environment— Guidance This device is intended for use in the electromagnetic environment specified below. The customer and/or user of this device should ensure that it is used in such an environment.

  • Page 9: Using The Avant 9600

    It may also be used in patient transport, sleep laboratories, and EMS environments. The Avant 9600 is intended for continuous monitoring and/or spot- checking of patients during both motion and no-motion conditions, and for patients who are well or poorly perfused.

  • Page 10: Installing The Batteries

    DO NOT use the device with- out batteries when patient safety relies upon audible alarms. NOTE: Contact NONIN to purchase or replace battery packs. NOTE: Reposition the back cover carefully, and tighten the screws...

  • Page 11: Verifying Avant 9600 Operation

    (initialization) sequence. Verify that all LEDs illuminate and the unit beeps three times during the first phase of the startup sequence. If any LED is not lit (except the AC Power Adapter LED), do not use the Avant 9600. Contact NONIN Customer Support for assistance.
  • Page 12 45 dB. Time, Month, Day, and Year LEDs These amber LEDs indicate that the Avant 9600’s Time, Month, Day, or Year displays can be reviewed or adjusted using the Plus (+) and Minus (-) buttons.
  • Page 13 In addition, this LED—when lit solidly—indicates that the battery charge is being displayed or the battery pack is not installed. This LED does not indicate that the Avant 9600 is running on battery power. The battery charge indication will not be accurate before one full charge/ discharge/recharge cycle with a new battery pack.
  • Page 14 Minus buttons are used to adjust time, date, volume, upper and lower alarm limits, and data output settings. Pressing either of these buttons alone, when the Avant 9600 is not in any setting mode, adjusts the intensity of the LED displays.

  • Page 15: Default Settings

    Once set, the adjusted values are used as defaults until the Avant 9600 is turned on with option switch 4 in the DOWN position, at which time the device restarts in Factory Default setting.

  • Page 16: User Functions

    Using the Avant 9600 User Functions Avant 9600 operating functions can be broken into Basic and Advanced groups. Basic Functions The Avant 9600 has several basic functions, which are easy to use and generally involve only a single button Function Button...
  • Page 17 Set Functions Set functions are those that require multiple buttons to alter a measurement or device parameter for normal operation. Function Button Instruction Set alarm limits. Momentarily press the Alarm Limits button to step through the Limits menu. Use the Plus or then Minus buttons to adjust alarm limits.

  • Page 18: Advanced Functions

    Press and hold both the Alarm Limits and ON/STANDBY buttons when turning on the Avant 9600. Memory Play- Press and hold the Time/Date button back and/or while turning on the Avant 9600. This Clear menu menu functions with NONIN’s ® nVISION software.

  • Page 19: Avant 9600 Option Switches

    Avant 9600 Option switches The Avant 9600 contains eight option switches that are located under the blue back cover of the unit (See “Installing the Batteries” for instructions on removing the back cover). The UP position faces the top of the unit, and the DOWN position faces the bottom of the unit.

  • Page 20: Nurse Call Feature

    The nurse call output signal is active when the 9600 is in Standby mode. The Nurse Call Circuit can be used both when the Avant 9600 is plugged in and when it is running on battery power. In addition, the nurse call output operates at any alarm volume setting—including when audible alarms are turned off.

  • Page 21: Care And Maintenance

    Clean the Avant 9600 with a soft cloth dampened with isopropyl alcohol. Do not pour or spray any liquids onto the Avant 9600, and do not allow any liquid to enter any openings in the device. Allow the unit to dry thoroughly before reusing it.

  • Page 22: Alarms And Limits

    Watchdog alarms are loud, two-tone, steadily beeping signals that indicate a hardware or software malfunction. When a watchdog alarm is activated, it can be cleared by shutting down the Avant 9600. If the watchdog alarm cannot be cleared, remove the battery and contact your distributor or NONIN Customer Support.

  • Page 23: Alarm Summary

    Avant 9600 will signal a high priority alarm, indicated by red numeric LEDs that flash in sync with the Main Alarm LED.

  • Page 24: Setting And Changing Volume And Alarm Limits

    Alarms and Limits Setting and Changing Volume and Alarm Limits NOTE: Avant 9600 alarm limits reset themselves to default values each time the unit is powered up—unless the unit is in Patient Security mode. In Patient Security mode, alarm limits and volumes cannot be adjusted;...

  • Page 25: Reviewing, Setting, Or Changing Serial Output Rates

    1 must be placed in the UP position. This allows the alarm volume to be set to zero. The Alarm Silence LED will remain illuminated when the alarm volume is set to less than 45 dB. Refer to “Avant 9600 Option Switches” for more information.

  • Page 26: Latched And Unlatched Alarms

    The Avant 9600 allows users to select Unlatched or Latched alarms. Option switch 3, located at the bottom of the Avant 9600 behind the back cover, is used to toggle between Latched Alarms and Unlatched Alarms modes. Unlatched mode (option switch 3 in the DOWN position) is the default.

  • Page 27: Patient Security Mode

    Security mode, users cannot view or set the alarm volume, pulse volume, or time and date. When the Avant 9600 is turned on in Patient Security mode, “111 111” blinks three times in amber on the display area, and three informational tones are sounded.

  • Page 28: Error Codes

    Alarms and Limits Error Codes The Avant 9600 includes error codes that indicate problems with the unit. To correct error conditions, perform the following steps: Turn the unit off and then back on again to remove the error code. If the error persists, disconnect all power (AC and battery), and then reconnect the power and turn the unit back on.

  • Page 29: Communication

    If you wish to create your own software, contact NONIN for the data format. The memory in the Avant 9600 functions much like an “endless loop” tape. When the memory fills up, the unit begins overwriting the oldest data with the new data.

  • Page 30: Playing Back Memory Data

    The Avant 9600 has a Memory Playback feature, allowing stored data to be output through the RS-232 serial connection. With the unit off, connect the RS-232 connector port of the Avant 9600 to the back of your computer using a null modem cable.

  • Page 31: Serial Patient Data Outputs

    The Avant 9600 provides real-time data output capability via the RS232 connector port. A null modem cable may be used to connect the Avant 9600 to the receiving computer. The information from the Avant 9600 is sent in an ASCII serial format at 9600 baud with 8 data bits, 1 start bit, and 2 stop bits.

  • Page 32: Using The Avant 9600 With Philips Vuelink

    • high and low SpO and pulse rate alarm limits NOTE: Limits set to “off ” on the Avant 9600 are reported to the VueLink module as the maximum values of the upper limits and the minimum values of the lower limits.
  • Page 33 Sensor Fault 3. No SpO Data 4. No Pulse Data 5. Low Battery The following text strings, associated with the Avant 9600, are sent through the VueLink module for display on the multiparameter monitor: Parameter Displayed Text Displayed High SpO2 Limit...

  • Page 34: Specifications

    S p e c i f i c a t i o n s Specifications OXIMETER 0% to 100% Oxygen Saturation Range (%SpO 18 to 300 pulses per minute Pulse Rate Range Displays 3-digit LEDs, Tricolor (red, green, amber) Numeric Displays Tricolor LED segments Pulse Strength Bargraph LED...
  • Page 35 SYSTEM Temperature +32° to +122°F (+0° to +50°C) Operating -22° to +122°F (-30° to +50°C) Storage/Transportation Humidity 10% to 90% noncondensing Operating 10% to 95% noncondensing Storage/Transportation 7.2 volt battery pack (6 cells) Power Requirements or 12 VDC 1.5A AC Adapter Battery Life minimum 12 hours of continuous operation Operating...
  • Page 36 S p e c i f i c a t i o n s Nurse Call 30 V, AC or DC (non-polarized), maximum Voltage 100mA continuous (maximum) Current 30 ohms (maximum) Output Impedance Isolated ground Ground Reference 1500 VDC Electrical Isolation Normally Open or Normally Closed;...

  • Page 37: Parts And Accessories

    Parts and Accessories Model Number Description AVANTB Battery Pack 9600 Manual Operator’s Manual for the Avant 9600 300PS-UNIV Battery Charger, Universal Desktop with IEC320 Connector Contact your distributor or Cord Set, Charger (must not exceed 2 meters) NONIN for options.
  • Page 38 Pole Mount Clamp Avant CC Carrying case for Avant products For more information about NONIN parts and accessories, contact your distributor, or contact NONIN at (800) 356-8874 (USA and Canada) or (763) 553-9968. This information is also available on NONIN’s website: www.nonin.com.

  • Page 39: Service, Support, And Warranty

    This warranty excludes cost of delivery to and from NONIN. All repaired units shall be received by the purchaser at NONIN's place of business. NONIN reserves the right to charge a fee for a warranty repair request on any Avant 9600 that is found to be within specifications.

  • Page 40: Troubleshooting

    The battery pack is Check the battery pack operate on batteries. inserted incorrectly. connection. The battery pack is not Plug in the Avant 9600 charged. AC Adapter to charge the battery pack. The battery pack is Contact NONIN Customer inoperable.
  • Page 41 There is excessive Shield the sensor from the pulse quality ambient light. light source. indication. The Avant 9600 is Apply the sensor to a finger applied to a polished or without artificial or polished artificial fingernail. nails. Position the sensor at a different site.
  • Page 42 The finger was removed Reinsert the finger and keep from the sensor. the sensor motionless for at least 10 seconds. The Avant 9600 is not Turn the unit off, check all functioning. connections, and retry. Contact NONIN Customer Support.
  • Page 43 The battery is missing. Contact your distributor or NONIN Customer Support for repair or replacement. If these solutions do not correct the problem, please contact NONIN Customer Support at (800) 356-8874 (USA and Canada) or +1 (763) 553-9968.
