Installation Requirements

The following conditions are required for installation of the equipment.
1. Power source should be rated as:
208V - 240V plus 6% or minus 10%, 50/60Hz, 16A or higher
2. The equipment must be on an exclusive circuit.
3. The outlet must be near the equipment and easily accessible.
1. Make sure to connect this equipment to a grounded outlet.
2. For PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near
the equipment and shall be easily accessible.
1. The installation site must not have open flames, dust or ammonia gases.
2. Not to be installed near solvent based printers, corrosive gases or devices that emit
them.
3. The equipment must not be exposed to the air vents from air conditioners.
It may affect the image quality.
4. The equipment should not be exposed to the direct sunlight.
Please draw curtains to block any sunlight.
When you open the Upper Unit to remove a mis-feed, do not expose the
Photoconductive Drum to strong (intense) light as this will damage the Drum.
Ventilate the room, if required.
The site temperature range = 10 to 30 degrees Centigrade, with the humidity between
15% to 80% RH. (NON-CONDENSING)
Keep the printer away from water sources, boilers, humidifiers, refrigerators, kerosene
(oil) stoves or other printers which emit gases.
Keep ample room around the equipment to ensure comfortable operation.
(Refer to the following figure.)
The equipment must be leveled and the floor strength must be ample to sustain the
weight of the equipment.
2700 mm
1500mm
600mm
Left
Front
Rear
Right
C
1-2
600mm
