NOTE
(1) Note the position of leading edge. It should be on the bottom side when directed to the
media feeding path.
Correct
to media feeding path
to media feeding path
Correct : Leading edge is on top side
(2) The outside rim (7) of the Flange must be aligned with the tip of black triangle (8) for
correct gear engagement. If not, the Flange may come off from correct position and may
result in incorrect media feeding.
OK
8
7
Correct
Incorrect
to media feeding path
Incorrect : Leading edge is on bottom side
8
7
2-9
NG
Wrong
Chapter 2 Basic Operations
