KIP 7170 User Manual
Version A.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7170 and is the answer not in the manual?

Questions and answers

Isaiah
January 30, 2025

why does red light flash while scanning mean how to make it go away

1 comments:
Mr. Anderson
February 10, 2025

A flashing red light on the KIP 7170 indicates that the Scan Abort Button has been pressed, stopping the current scan or copy process immediately. This also halts any ongoing printing, and the document is ejected. To resolve this, restart the scanning or copying process as needed. Avoid pulling back or holding down the original on the Original Table to stop feeding.

This answer is automatically generated

Summary of Contents for KIP 7170

  • Page 1 KIP 7170 User Manual Version A.0...
  • Page 2 Thank you for purchasing the Multi-Function Printer KIP 7170. This Hardware Operation Guide contains functional and operational explanations for the KIP 7170. Please read this Hardware Operation Guide carefully before using the printer. Please keep this Hardware Operation Guide for future reference.
  • Page 3: Safety Warnings

    Safety Warnings The following warnings are very important in order to safely use this product. These notes are important in preventing danger to the operator or operation of the printer. The following symbols are found throughout the USER’S Manual and have the following meaning: WARNING This WARNING mark means that there is a possibility of death or serious injury if you ignore or do not follow the said instruction.
  • Page 4 WARNING Ground the product with a correct ground source or you may be electrically shocked. 1. The Power source should be as follows: In U.S.A. : 120V plus/minus10%, 50/60Hz, 15A or higher In Europe : 220-240V plus6% or minus10%, 50/60Hz, 10A or higher 2.
  • Page 5 CAUTION Do not install the printer in a humidified room or a dusty room. Also, do not install the printer on an unstable floor as injuries may occur. 1. Unplug the printer before you move it. The power cord may be damaged and it may result in a fire or electric shock.
  • Page 6 POWER CORD INSTRUCTION The installation of (or exchange to) a power plug which fits in the wall outlet of the installation location shall be conducted in accordance with the following: WARNING Select a power plug which meets the following criteria; - The plug has a voltage and current rating appropriate for the product’s rating marked on its name plate.
  • Page 7: Table Of Contents

    Chapter 1 Before Use Page 1. 1 Installation Requirements 1- 2 1. 2 Originals Prohibited from Duplication 1- 3 1. 3 Features 1- 4 1. 4 Specifications 1- 5 1. 4. 1 General 1- 5 1. 4. 2 Printer part 1- 6 1.
  • Page 8: Installation Requirements

    The equipment must be leveled and the floor strength must be ample to sustain the weight of the equipment. 30cm/12” or larger (Rear) (w/o option) KIP 7170 * L + R = 35cm/14” or larger (R must be larger than L) (L = 5cm/2” or larger (Front) 80cm/32”...
  • Page 9: Originals Prohibited From Duplication

    1. 2 Originals Prohibited from Duplication It is not necessarily allowed to copy every kind of original. You may be punished by the law if only you possess the copy of some kind of original. We recommend you to consider enough before you copy such original. [Originals prohibited from copying by the law] 1.
  • Page 10: Features

    (9) Contactless IC card reader for more efficient accounting management (option) (10) The KIP 7170 adopts 12.1 inch screen for the UI, wider than 10.4 for our old products. The capacitive multi-touch screen offers smooth, various and intuitive user operation that a pressure sensing device lacks.
  • Page 11: Specifications

    1. 4 Specifications 1. 4. 1 General Subject Specification Model KIP 7170 Configuration Console Power consumption 1,440W (US model) (Maximum) 1,680W (EU / Asia model) (scanner / controller included) Power consumption 8.2W or less (Low power mode) Acoustic noise Idling Max.
  • Page 12: Printer Part

    1. 4. 2 Printer part Subject Specification Printing method LED Array Electro photography Photoreceptor Organic Photoconductive Drum Print speed 80mm per second (Inch) 3.4ppm/E 5.8ppm/D Landscape (Metric) 3.3ppm/A0 5.6ppm/A1 Landscape Print head LED Array Resolution of print head 600dpi x 2400dpi Print width Maximum 914mm / 36”...
  • Page 13 Subject Specification Media source 2 Roll Decks Manual Feeder (single cut sheet) Paper Tray (multiple cut sheet, option) Media (Recommended Media) US model: Bond 64g/m to 80g/m , US Bond (PB-20) Vellum US Vellum (XV-20) Film 4MIL (PF-4DDME) Europe/Asia model: Plain Paper 64g/m to 80g/m...
  • Page 14: Scanner Part

    1. 4. 3 Scanner part Subject Specification Scanning method Contact Image Sensor (CIS) (5 pieces of A4 sized CIS) Light source LED (R/G/B) Setting of original Face up Starting point of scan Center Scan width Max: 914.4mm / 36” Min : 210mm Scan length Max:...
  • Page 15: Appearance

    Front view (OPTION) Name Function Main Switch You can turn on/off the KIP 7170. Original Guides Feed the original under the Scanner Unit along the Original Guides. User Interface This is a Touch Screen, and many kinds of user operation are available.
  • Page 16: Rear View

    For an optional device Service Use. 5VDC max. LAN Port Connect the LAN Cable to connect the KIP 7170 to the network. (Do not connect a telephone line) Dehumidify Heater Switch Turn on the Dehumidify Heater with this switch when you (Optional in the US) would like to dry the paper in the humid season.
  • Page 17: Specifications For The Scan Original

    1. 6 Specifications for the Scan Original A scan original must satisfy the following specifications. Thickness 0.05mm to 1.6mm Width 210mm to 914.4mm Length 210mm to 6000mm *1. Image quality for an original with 0.25mm or thicker is guaranteed only in a standard size even the scanner physically accepts it. *2.
  • Page 18 Not square K I P K I P Metal or fabric material Metal Fabric K I P K I P Rough surface Rough surface (Carbon paper for example) Clipped or stapled Clipped Stapled K I P K I P 1-12 Chapter 1 Before Use...
  • Page 19 The following kinds of originals can be read with using a carrier sheet. Image quality or the reliability of paper feeding for them is not guaranteed. Patched Punched 1-13 Chapter 1 Before Use...
  • Page 20: Specifications For The Printing Paper

    1. 7 Specifications for the Printing Paper 1. 7. 1 Papers not available to use Do not use the following kinds of printing paper. Doing so may damage the print engine. Excessively curled (a diameter of 50 mm or less) Folded Creased Torn...
  • Page 21: Keeping The Paper In The Custody

    Pre-printed Extremely slippery Extremely sticky Extremely thin and soft OHP Film CAUTION Do not use the paper with staple, or do not use such conductive paper as aluminium foil and carbon paper. The above may result in a danger of fire NOTE (1) Print image may become light if printed on a rough surface of the paper.
  • Page 22: Treatment Against Environmental Condition

    High NOTE (1) KIP 7170 is equipped with the Dehumidify Heater (optional for the US). Using it in high humidity environment (75% or higher) is recommended. Refer to [2.9 Dehumidifying Roll Paper]. (2) “Void of image” and “crease of paper” will occur in case of extremely high or low humidity.
  • Page 23 Chapter 2 Basic Operation Page 2. 1 Turning on KIP 7170 2- 2 2. 2 Turning off KIP 7170 2- 4 2. 3 Replacing Roll Media 2- 5 2. 4 Replacing Toner Cartridge 2-11 2. 5 Cut Sheet Media 2-15 2.
  • Page 24: Turning On Kip 7170

    In Europe : 220-240V plus 6% or minus 10%, 50/60Hz and 10A 2. Press “ | ” side the Power Switch on the right side of the printer to turn on the KIP 7170. Power Switch Press “ | “ side.
  • Page 25 Ready Indicator The UI screen may vary depending on your system configuration. (Shown with available options) 4. When Ready Indicator stops flashing, the KIP 7170 is ready for operation. NOTE It is impossible to make any prints while Ready Indicator is flashing in orange.
  • Page 26: Turning Off Kip 7170

    ” side. CAUTION The KIP 7170 print engine and UI appear to be shut down when you turn off KIP 7170. However, the controller PC embedded inside the KIP 7170 is still operating and will shutdown in approximately two minutes after Power Switch operation.
  • Page 27: Replacing Roll Media

    2. 3 Replacing Roll Media (1) When the printer is running out of a roll media, the UI Screen will Ddisplay “Roll Replacement” sign. Follow the later procedure (or as noted in the UI’s User Guide) to load a roll media.
  • Page 28 3. Raise the green lever (4) on Flange (2). Remove both Flanges (4) from the roll core (3). 4. Move a right Slide Guide (5) to match your roll media’s width. The right and left Side Guides will automatically move together. 5: for Roll 2 Size markings Chapter 2 Basic Operation...
  • Page 29 5. Insert each Flange (2) into both ends of the roll media core to be installed. NOTE (1) Fully insert Flange into the roll media core so that the inside rim of Flange evenly touches the side face of the roll media. Inside Rim Inside Rim Correct: Fully inserted...
  • Page 30 7. Lift the roll media by holding both Flanges. Lower Flanges onto Slide Guides (5) in Roll Deck. NOTE (1) Be careful of the winding direction of the roll media. Rear: Deck back Rear: Deck back Front: to media path Front: to media path Correct: Edge comes from bottom Wrong: Edge comes from top...
  • Page 31 8. Insert the leading edge of the roll media under Guide Plate (8) until it touches the feeding roller. Rotate Feed Knob (9) clockwise so that the feeding rollers catch the leading edge. NOTE Use the rear Feed Knob (10) for Roll Deck 2. 9.
  • Page 32 10. Slide the green Cutter Knob (12) fully from one side to the other to make a new straight edge. Remove the cut portion. NOTE Completely slide Cutter Knob (12) until it stops at either end. Not doing so may cause a paper jam. Correct Wrong 11.
  • Page 33: Replacing Toner Cartridge

    Toner Cartridge with a new one (genuine). NOTE (1) The KIP 7170 will indicate Toner Empty sign if an incorrect toner cartridge or no toner cartridge is installed to the printer. (2) At the machine’s installation, some amount of initial toner powders will be supplied to the machine.
  • Page 34 2. Slide the green Lever (2) to the right to unlock the Toner Cartridge. (Lever (2) is held automatically.) NOTE Be sure to unlock the Toner Cartridge by releasing the green Lever (2). Correct: disengaged Wrong: not disengaged (The green Lever (2) is shifted to the right.) 2-12 Chapter 2 Basic Operation...
  • Page 35 3. Pressing down the Cartridge Lock Lever (3), turn the body (4) of cartridge to the arrow direction until it stops. (You can close the toner supply hole of the cartridge firmly by this) NOTE The toner may drop from the toner supply hole, and it may scattered into the machine or on the floor if you remove the Toner Cartridge without closing the toner supply hole (5).
  • Page 36 5. Shake the new Toner Cartridge left and right 5 times or more to make the toner smooth. After shaking, tilt the Toner Cartridge to the cap side. Cap Side 6. Keep pressing down the Cartridge Lock Lever (3). Direct the toner supply hole to the floor, fit the pin (6) on the left side of the cartridge to the groove (7) on the machine side.
  • Page 37 7. Turn the body (4) of the cartridge in one revolution to the arrow direction to open the toner supply hole. Confirm that the projection (8) if fitted into the notch (9). NOTE It is not necessary to lock the cartridge with the Lever (2).
  • Page 38: Cut Sheet Media

    2. 5 Cut Sheet Media 1. Open the Bypass Feeder (1). Bypass Feeder 2. There are several size markings on the table of Bypass Feeder which indicate possible feed positions. Place the cut sheet paper on the table between its concerning size markings then insert it into the Bypass Feeder.
  • Page 39: Copying

    2. 6 Copying 1. There are several size markings on Original Table which indicate possible feed positions. Line up Original Guides with the proper markings according to the original width. Original Guide Original Guide 2. Place the original on the Original Table with face up. Then insert it under the Scanner Unit along with Original Guides.
  • Page 40 3. The KIP 7170 will start the copy process. Reference Pressing START button may be required to start the scan according to the scanner’s controller software. Start Button For further details of “Auto Start”, see the software’s document. NOTE The scanner unit does not accept originals automatically during Sleep Mode. Tap on the UI screen and then insert an original.
  • Page 41 The KIP 7170 has 2 print delivery system, the print tray (front, standard) / rear stacking equipment (back, option). NOTE For the front stacking, gently lift up the prints on the print tray to the arrow direction to avoid rubbing the print surface. A large number of prints should be removed in several sheets.
  • Page 42 2. 7 Stop of Scan or Copy 1. If necessary, press the Scan Abort Button on the Scanner Unit to immediately stop the original while making a copy or scan. The LED Indicator flashes red. flashing Scan Abort Button Pressing the button stops the current reading a document immediately. The current printing is stopped as well and is ejected.
  • Page 43: Canceling Sleep Mode

    NOTE (1) It may take time for the machine to get ready. (2) Tapping on the UI screen can cancel the screensaver but the KIP 7170 needs to recover temperature on Fuser Unit. It may need another waiting time to start warming up for printing.
  • Page 44: Dehumidifying Roll Media

    Loss of image If the media is humidified; If the KIP 7170 is installed in such a condition, it is recommended to use the optional embedded “Dehumidify Heater”. Turn on the Dehumidify Heater if the room air has too much humidity (75% or higher) to prevent the above kinds of print defect.
  • Page 45 Chapter 3 Error Correction Page 3. 1 Mis-feed Error 3- 2 3. 1. 1 Deck Jam / Feeding Jam 3- 2 3. 1. 2 Manual Jam 3- 5 3. 1. 3 Reg. Jam / Internal Jam 3- 6 3. 1. 4 Fuser Jam 3- 7 3.
  • Page 46: Mis-Feed Error

    3. 1 Mis-feed Error NOTE (1) Be careful not to get paper cuts on your hand. (2) It is recommended to take off your ring, bracelet or watch when removing a mis-feed media. (3) Gently remove a jammed paper. When it does not reach Fuser Unit, toner on it may spill off.
  • Page 47 3. Insert the leading edge of the roll media under Guide Plate (2) until it touches the feeding roller. Rotate Feed Knob (3) clockwise so that the feeding rollers catch the leading edge. NOTE (1) The leading edge should be trimmed with a cutter in case of an extreme crease.
  • Page 48 5. Slide the green Cutter Knob (6) fully from one side to the other to make a new straight edge. Remove the cut portion. NOTE Completely slide Cutter Knob (6) until it stops at either end. Not doing so may cause a paper jam. 6.
  • Page 49: Manual Jam

    3. 1. 2 Manual Jam 1. Remove all Print Trays (1). 2. Pull up the Engine Unit Open Levers (2) to open the Engine Unit. 3. Remove the mis-fed paper pulling frontward. mis-fed media Chapter 3 Error Correction...
  • Page 50 4. Gently close the Engine Unit. NOTE (1) Be sure to close the Engine Unit firmly until it locks at the correct position. (2) The mis-feed cut sheet should be replaced with a new one if its leading edge has a torn or fold.
  • Page 51: Reg. Jam / Internal Jam

    3. 1. 3 Reg. Jam / Internal Jam 1. Remove all Print Trays (1). 2. Pull up the Engine Unit Open Levers (2) to open the Engine Unit. 3. Remove the mis-fed paper. mis-fed media Chapter 3 Error Correction...
  • Page 52 4. Gently close the Engine Unit. NOTE Be sure to close the Engine Unit firmly until it locks at the correct position. 5. Replace Print Trays in the original position. Chapter 3 Error Correction...
  • Page 53: Fuser Jam

    3. 1. 4 Fuser Jam 1. Remove all Print Trays (1). 2. Pull up the Engine Unit Open Levers (2) to open the Engine Unit. 3. Remove the mis-fed paper. If the mis-fed paper cannot be seen or removed, leave the media and go to the next step. If the paper (including any torn part) can be removed, go to step 8.
  • Page 54 5. Pull and remove the jammed print to the rear. If you remove the print at this time, just close the Exit Cover. If the print cannot be removed, go to the next step. If the print (including any torn part) can be removed, go to step 8.
  • Page 55 7. Close Fuser Door (5) and Exit Cover (3). 8. Gently close the Engine Unit. NOTE Be sure to close the Engine Unit firmly until it locks at the correct position. 9. Replace Print Trays in the original position. 3-11 Chapter 3 Error Correction...
  • Page 56: Stack Jam

    3. 1. 5 Stack Jam 1. Remove print(s) on Print Trays. 2. Remove all Print Trays (1). 3. Pull up the Engine Unit Open Levers (2) to open the Engine Unit. 4. Pull and remove the jammed print to the top. If the print cannot be removed, see [3.1.4 Fuser Jam] for the later procedure of clearing the jammed print.
  • Page 57 5. Gently close the Engine Unit. NOTE Be sure to close the Engine Unit firmly until it locks at the correct position. 6. Replace Print Trays in the original position. 3-13 Chapter 3 Error Correction...
  • Page 58: Original Jam

    3. 1. 6 Original Jam The scanner may stop feeding the original in the scanner if the original skews. flashing Pressing Scan Abort Button during scanning also stops the original in the scanner. Scan Abort Button In both cases, LED Indicator flashes red. 1.
  • Page 59: Accessory Jam

    3. 1. 7 Accessory Jam The printing paper is mis-fed in the optional device such as Auto Stacker or Folder. Remove the mis-fed paper making reference to the User’s Manual of concerning device. 3-15 Chapter 3 Error Correction...
  • Page 60: Other Operator Call Error

    3. 2 Other Operator Call Error 3. 2. 1 Roll Replacement When the printer is running out of an loaded roll media, the UI Screen will display “Roll Replacement” sign. If there is no suitable roll media required for the current print job, the UI Screen will display “Roll Replacement”...
  • Page 61: Service Call Errors

    1. Turn off KIP 7170, and turn it on after an interval of 30 seconds or more. 2. If the same error code appears, turn off KIP 7170, and then unplug the printer from the wall outlet after an interval of two minutes for shutdown.
  • Page 62 Chapter 4 Maintenance Page 4. 1 Scanner Unit 4- 2 4. 1. 1 Scan Glass, Feed Roller, Guide Plate 4- 2 4. 1. 2 Sensor 4- 5 4. 2 Touch Screen 4- 7 Chapter 4 Maintenance...
  • Page 63: Scanner Unit

    NOTE For ease of visual check, this document shows the Upper Unit fully open (not actual wide). 1. Turn off KIP 7170. 2. Lift up both sides (1) of the Scanner Unit. Chapter 4 Maintenance...
  • Page 64 3. Gently wipe the Scan Glass (2) and Feed Rollers (white) (3) with a soft cloth. Equal mixture of water and neutral detergent can be used. NOTE Do not use organic solvent, glass cleaner and anti-static spray for the cleaning. 4.
  • Page 65 6. Wipe the Upper Guide Plate (5) and the Lower Guide Plate (6) with a dry cloth. 7. Gently press Scanner Unit down and firmly close it. NOTE Press down Scanner Unit on both side to close it. Do not close it by pressing only one side down. Chapter 4 Maintenance...
  • Page 66: Sensor

    Perform cleaning or as needed. NOTE For ease of visual check, this document shows the Upper Unit fully open (not actual wide). 1. Turn off KIP 7170. 2. Lift up both sides (1) of the Scanner Unit. Chapter 4 Maintenance...
  • Page 67 3. Gently wipe Sensors (2) with a dry cotton bud. NOTE Do not use water, organic solvent, glass cleaner or antistatic spray for cleaning. 4. Gently press Scanner Unit down and firmly close it. NOTE Press down Scanner Unit on both side to close it. Do not close it by pressing only one side down.
  • Page 68: Touch Screen

    4. 2 Touch Screen 1. Wipe the Touch Screen with a dry cloth. NOTE Do not use water, alcohol, organic solvent and glass cleaner for the cleaning. Chapter 4 Maintenance...
