Left Side View - KIP 600 Series User Manual

1. 5. 2

Left side view

4
Name of part
1 Toner Supply Port
2 Left Side Door
3 Waste Toner Box
4 Purge Switch
5 Feeder Release
Knob
2 3
Function
Toner Cartridge (C, M, Y, K) to be set here to add toner to the
system.
Access Waste Container, Purge Switch and Feeder Release Knob.
Collects the wasted toner.
After removing jammed sheets, press this switch to eject remaining
sheet from the printer.
Unlocks the Feeder Unit to clear misfeeds.
1
5
