1 Installing the Router
DSL:
ADSL and ADSL2+ interface (both over PSTN and ISDN).
Fig. 14: Teldat C1+ model: ADSL connectors
Fig. 15: Teldat C8+ model (external source): ADSL connector
Fig. 16: Teldat C8+ model (internal source): ADSL connector
Fig. 17: Teldat C9+ model (external source): ADSL connector
Fig. 18: Teldat C9+ model (internal source): ADSL connector
ISDN:
Basic ISDN 2B+D interface: this has a trigger mechanism, which in some devices is a switch (TERM), and in others,
consists of 2 ports (to introduce the S bus termination load).
You need a software license for operating purposes.
Fig. 19: Teldat C1+ model: ISDN connector
Fig. 20: Teldat C8+ model (external source): ISDN connector and TERM pushbutton
Fig. 21: Teldat C8+ model (internal source): ISDN connector and TERM pushbutton
